Preparations; Installing The Ailerons - Phoenix Model PH 165-OUTRAGEOUS Instruction Manual

Instruction Manual

PREPARATIONS

Use a covering iron with a covering sock on
high heat to tighten the covering if necessary.
Apply pressure over
thoroughly bond the covering to the wood.

INSTALLING THE AILERONS

1. Test fit the ailerons to the wing with the hinges.
If the hinges don't remain centered, stick a pin
through the middle of the hinge to hold it in
position.
2. Apply six drops of thin CA to the top and bottom
of each hinge. Do not use CA accelerator. After
the CA has fully hardened, test the hinges by
pulling on the aileron.
Main Wing
Aileron
sheeted areas to
< Bottom view >
8
OUTRAGEOUS
TEMPORARY PIN
TO KEEP HINGE
CENTERED
