INSTALLING THE MAIN LANDING GEAR

2
8mm Nut
2
4mm Collar
4
8mm Washer
4
4 x 20mm Cap Screw
2
4 x 30mm Cap Screw
2
4mm Washer
4
4mm Spring Washer
4
Cut off shaded portion
Assemble left and right
sides the same way
< Main Gear (R) >
< Left >
4x20mm
4x20mm
4mm
5
OUTRAGEOUS
< Main Gear (L) >
< Bomb >
< Right >
4mm
