NOTE:
The components identified by
!
mark
are critical for safety.
Replace only with part number
specified.
Les composants identifies par
!
une marque
sont critiques
pour la securite. Ne les
remplacer que par une piece
portant le numero specifie.
MIC
S
Chassis
SECTION 8
ELECTRICAL PARTS LIST
. Items marked "*" are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
. All variable and adjustable resistors have
characteristic curve B, unless otherwise noted.
RESISTORS
. All resistors are in ohms
. F: nonflammable
When indicating parts by reference number,
please include the board name.
. CAPACITORS
PF: µµ F
. There are some cases the reference number on
one board overlaps on the other board. Therefore,
when ordering parts by the reference number,
please include the board name.
. The components identified by
have been carefully factory-selected for each set
in order to satisfy regulations regarding X-ray
radiation.
Should replacement be required, replace only with
the value originally used.
in this manual
8-1
