- Page 1 Order no. 3046/00...
- Page 2 The Pilot is a based loosely on a modern 20 m pilot vessel. Boats of this kind are encountered along the Baltic and North Sea coasts, and are very fast - around 25 - 30 kn - and manoeuvrable. Their task is to transport pilots safely to the great ocean giants, regardless of the weather.
- Page 3 A certain amount of sanding at an angle is required on the laser-cut parts and some sub-assemblies, since the laser can only cut at an angle of 90°. Please use a fine file or a sanding block with abrasive paper glued to it for this purpose.
- Page 4 Glue the hull sides to the frames and stringers on the inside. Important! the hull sides must make contact with the keel at the bow, and engage in the notches in the frame Fig. 3 lugs. Leave them in this position while the glue hardens. The lateral edges of the hull bottom panels 15 must be bevelled towards the inside of the hull to ensure neat joints with the hull sides.
- Page 5 Do not press the bottom panels against the frames, as this would produce irregularities in the hull skin. Glue the bottom panels to the frames where they touch, but without exerting pressure. Sand the hull sides lightly at the stern to follow the bevel of the transom, using a sanding block or a file.
- Page 6 Fig. 9 The hull can now be lifted from the jig, and the support lugs on the frames removed: you can either snip off the lugs using side-cutters, or carefully break them off. Sand the cut or broken edges smooth. Attach the shaft couplings 20 to the shafts 18, then Fig.
- Page 7 Insert the rudders 33 from the underside. Fit 1 cm lengths of silicone tubing 36 on the rudder shafts from the top, and push them down until they rest on the rudder bushes. Open up the outer hole in the single-armed tiller 34 to 2.0 mm diameter.
- Page 8 Curve the bulwark sections 51 slightly towards the bow by pulling them over the edge of a table. Fit both bulwark components in the slots in the deck. Carefully sand the front edge of both parts 51 where they meet, so that a watertight glued joint can be produced.
- Page 9 Cut the railing components 62 and 67 to length from 1.5 mm Ø nickel-silver wire, and bend them to the shape shown in the Fig. 13.4 bending template in sheet 2. Solder the joints with the parts in the template. Paint the step sides 64 and 64.1, and glue three treads 65 and one platform 66 between them.
- Page 10 Glue together parts 79 to 81 to form the instrument Fig. 16 panel. Apply the instrument decal 83 to the panel. Stick the etched bezel 82 to the decal sheet using contact adhesive. Apply low-tack masking film to part 82, keeping accurately to the edges, to protect it from subsequent painting.
- Page 11 Bend the front windows 94 and 95 to the rear along the engraved lines, and glue them in the Fig. 19 slots in the instrument panel 79. Bend the centre and side cover panels 96 and 97 along the engraved lines, and glue them to the front panels 91 and 92, the side walls 90 and the front windows.
- Page 12 Fig. 22 Glue the seat squab 118 to the front section 119 and the bottom section 117. Bend the side panel 120 inwards slightly along the engraved lines. Fit the seat squabs in the side panels. Insert the backrest 121 and the backrest side fairings 122.
- Page 13 Fig. 26 Glue the two inner mast sections 141 to one outer section 142, cut away the connecting lugs 2x141 as shown, then glue the other outer section 142 on top. Thread the cables for the LEDs through the mast, and glue the spreaders 143 in place. Glue the locating pin 147 in the mast;...
- Page 14 Complete the wheelhouse with the handrails 160 - 161. Apply a strip of adhesive tape over the front of the PILOT name placard to hold the letters in position, then remove the letters from the etched parts sheet. Apply a little contact cement or canopy glue...
- Page 15 The circuit shown is only a suggestion. The lighting system components are not included in the kit. 1. Panoramic light, flashing light, yellow Masthead 2. Running light 3. Panoramic light, pilot 4. Panoramic light, mooring light Stern 5. Panoramic light, flasher, blue 6. Searchlight 7.
- Page 16 N ° D escription Q uant. M atière Feuille D im ensions 0 C hantier de construction 13m m D epron 1 C ouple 11,5m m ABS 2 C ouple 11,5m m ABS 3 C ouple 11,5m m ABS 4 C ouple 11,5m m ABS 5 C ouple 11,5m m ABS...
- Page 17 No. Description Quant. Material Sheet Dimensions Searchlight lens 2 1.0 mm VIVAK Step tread 1 0.5 mm nickel-silver Etched Step tread 3 0.5 mm nickel-silver Etched Railing stanchion 8 1.5 x 80 mm NS wire Overlength Handrail 2 1.5 x 230 mm NS wire Overlength, bend to shape Step side rail 2 1.5 mm ABS...
- Page 18 No. Description Quant. Material Sheet Dimensions 119 Seat front section 1 1.0 mm ABS 120 Seat side section 2 1.0 mm ABS Two-part, engraved 121 Seat backrest 1 1.0 mm ABS Two-part, engraved 122 Seat backrest side fairing 1 1.0 mm ABS Two-part, engraved 123 Seat top cover 1 1.0 mm ABS...
- Page 19 20 mm searchlight Order No. 566720 The searchlight swivels and tilts, and its articulation can be controlled by mini-servos. The LED must be fitted with a series resistor! Bend the sides of part 1 through 90° as shown. Insert the sides 2 and solder the box joints on the inside.
- Page 20 Other models in our range Alex 3047/00 Jenny 3055/00 Bellissima 3012/00 Victoria 3082/00 and there are plenty more at www.aero-naut.com aero naut aero-naut Modellbau Stuttgarter Strasse 18-22 D-72766 Reutlingen www.aero-naut.com...
