Introduction:
The model should be assembled following the sequence of the part numbers. These instructions are arranged by
stages in the correct order.
You may need to use a thin modelling knife to release the laser-cut parts from the sheets by cutting through on the
reverse side. The dark edges of the laser-cut parts should also be rubbed off using abrasive paper or a sanding pad
in order to obtain sound glued joints.
Check that all components fit accurately before reaching for the glue, and carry out any minor trimming required.
Allow all glued joints to dry out fully before starting the next stage of construction. We recommend a fast-setting
waterproof white glue for all joints.
We recommend that you apply a coat of sanding sealer (Order No. 7666/02) to all the wooden components and
sand the surfaces smooth before painting them.
We recommend our aero-pick
modelling pins, Order No. 7855/02, to
hold parts together when building the
model.
Tip: the laser-cut sheets include a large quantity of excess
material which is not required for building the model. It is a
good idea to place this material to one side, as it can be
used later to make handles, latches, fuel filler stubs and
similar, which help to give your model a livelier
appearance.
Order No. 3048/00
This model is not a toy. If a young
person under 14 years is to build and
operate it, a responsible adult must
supervise the activity.
RC functions
Optional
Specification
Length
Beam
Overall height
RC
Motor
Servo
Battery
Rudder
Forward / reverse
Lighting system
455 mm
200 mm
395 mm
Min. two channels
Race 600 (7124/21)
Standard
6 V lead-acid, 7.2 V NiXX
or 7.4 V LiXX
Advertisement
Related Manuals for Aeronaut Rambotator
Summary of Contents for Aeronaut Rambotator
- Page 1 Order No. 3048/00 This model is not a toy. If a young person under 14 years is to build and operate it, a responsible adult must supervise the activity. Introduction: The model should be assembled following the sequence of the part numbers. These instructions are arranged by stages in the correct order.
- Page 2 Glue the deck beams (1) to the deck reinforcement (2). Glue the hull sides (3) to the deck reinforcement. Glue all the hull bottom beams (1) in place as shown. Check that all the parts are at right- angles to each other before leaving the glue to set hard.
- Page 3 Use the shaft coupling to connect the propeller shaft to the motor shaft. Attach your preferred connectors to the power wires, then solder the wires and capacitors to the motor terminals. Screw the motor plate (11) to the motor. Glue the wedge (10) to the underside of the hull bottom (7). Fit the prepared motor assembly through the slot in the hull bottom (7) from the inside, then fit the shaft support (9) through the bottom (7) from the outside, sliding it into the slot in the motor mount (11).
- Page 4 Glue three strips of adhesive tape to the outside edges of the top face of the deck (22), overlapping all round as shown. Lay the deck on a flat surface with the adhesive tape on the underside, and glue the three rubbing strakes (83 + 84) to the edges.
- Page 5 Now glue the three remaining deck beams (1) in the notches in the hull. At this stage the whole of the hull and deck should be given two coats of sanding sealer. Install the motor in the hull, and cover it to protect it from soiling. The deck can now be attached to the hull: apply plenty of glue to all the joint surfaces of the hull and deck beams, and place the deck in position.
- Page 6 Assemble the rear hatch components (27, 28, 29) and glue the joints. Assemble the parts of the engine room (30, 31, 32, 30.1) and glue the joints, taking care to 30.2 position the roof (32) correctly; note the location of the holes (see arrows). Remove any rough edges from the inside edges of the engine room side panels (30, 31), as this 30.1...
- Page 7 Assemble the return pulleys as shown in the picture. Allow the glue to dry and paint them before gluing them in the holes in the deck. 43.1 42 42 Assemble the dolphin posts as shown in the picture, then prime and paint the surfaces before gluing them in the 45.1 slots in the deck.
- Page 8 71+67 Thread the railing stanchions (79) onto the lower rails (80) and the handrail (81), bending all three rails at the same time. Insert the railing stanchions in the holes in the engine room roof. Position the railing components carefully before gluing the rails to the stanchions.
- Page 9 All the windows (95) can now be installed, and the screen wiper (94) fitted.
- Page 10 Push a piece of silicone tubing (82) about 10 mm long onto the rudder shaft (17). Install the steering servo. Push a piece of silicone tubing (82) about 10 mm long onto the rudder bush (16) where it projects at the top. Fit the propeller (not included in the kit) on the propeller shaft, and secure it by tightening the locknut.
- Page 11 Bezeichnung Anzahl Platte Nr. Material/ Abmessung 1 Deck- und Bodenbalken Kieferleiste 5 x 5 x 200mm 2 Deckverstärkung vorne Laserteil, Sperrholz. 2mm 3 Seitenteile Laserteil, Sperrholz. 2mm 4 Heckspiegel Laserteil, Sperrholz. 2mm 5 Eckverstärkung hinten 6 x 6 x 33mm Dreikantleiste 6 Eckverstärkung vorn 6 x 6 x 20mm Dreikantleiste 7 Bodenplatte...
- Page 12 Nr,. Bezeichnung Anzahl Platte Nr. Material/ Abmessung 51 Steuerhausseite vorn Laserteil, Sperrholz. 2mm 52 Steuerhaus Frontfenster Laserteil, Sperrholz. 2mm 53 Armaturenträger Laserteil, Sperrholz. 2mm 54 Steuerradhalter Rundholz Buche Ø 10 x 15mm 55 Fahrhebelgehäuse Rundholz Buche Ø 10 x 10mm 56 Fahrhebel MS-Draht Ø...
