HARDWARE INSTALLATION GUIDE
Brocade FastIron SX Series Chassis
Hardware Installation Guide
Part Number: 53-1003613-04
Publication Date: 15 June 2017

Advertisement

Table of Contents
loading

Related Manuals for Brocade Communications Systems FastIron SX

Summary of Contents for Brocade Communications Systems FastIron SX

  • Page 1 HARDWARE INSTALLATION GUIDE Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04 Publication Date: 15 June 2017...
  • Page 2 United States government. The authors and Brocade Communications Systems, Inc. assume no liability or responsibility to any person or entity with respect to the accuracy of this document or any loss, cost, liability, or damages arising from the information contained herein or the computer programs that accompany it.

  • Page 3: Table Of Contents

    Installing mounting brackets on the FSX 1600 chassis............................... 53 Removing the slot panels............................................ 55 Installing management and interface modules...................................55 Attaching a management station........................................62 Attaching a PC or terminal to the console port or 10/100/1000 copper port....................63 Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 4 Management module switchover......................................110 Switchover implications..........................................111 Management module redundancy configuration................................... 112 Changing the default active chassis slot................................... 112 Managing management module redundancy..................................112 File synchronization between the active and standby management modules....................112 Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 5 Displaying the status of the power supplies..................................149 Replacing the FSX 800 fan tray........................................149 Replacing the FSX 1600 fan assemblies....................................152 Replacing the air filter in the FastIron SX-1600..................................154 Mean time between failure..........................................155 Brocade FastIron SX Series Technical Specifications............................159 System specifications............................................159...
  • Page 6 Caution and Danger Notices....................................... 173 Cautions................................................... 173 General cautions............................................173 Electrical cautions............................................174 Danger Notices..............................................178 General dangers............................................179 Electrical dangers............................................179 Dangers related to equipment weight....................................181 Laser dangers.............................................. 182 Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 7: Preface

    Identifies keywords and operands. Identifies the names of GUI elements. Identifies text to enter in the GUI. italic text Identifies emphasis. Identifies variables. Identifies document titles. Identifies CLI output. Courier font Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 8: Command Syntax Conventions

    Provide the publication title, part number, and as much detail as possible, including the topic heading and page number if applicable, as well as your suggestions for improvement. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 9: Contacting Brocade Technical Support

    Brocade Supplemental Support augments your existing OEM support contract, providing direct access to Brocade expertise. For more information, contact Brocade or your OEM. • For questions regarding service levels and response times, contact your OEM/solution provider. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 10 Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 11: About This Document

    For information about the features supported on a hardware platform, refer to the appropriate Features and Standards Support Matrix document. What’s new in this document There are no enhancements in this edition. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 12 Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 13: Overview

    Software features differ depending on the software version that is loaded on the device and the type of management module that is installed in the device. Refer to the appropriate configuration guide for a complete list of software features supported on your device. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 14: Supported Configurations

    • Built-in mounting brackets The following sections provide more information about these components. For details about physical dimensions, power supply specifications, and pinouts, refer to the “Hardware Specifications” section. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 15: Fsx 800 Chassis

    A slot panel in each empty interface module slot and power supply slot. The slot panels ensure proper airflow within the chassis. • One AC power supply • A fan tray assembly, which contains the cooling system for the chassis Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 16 Slot 3 10. Slot 10 Slot 4 11. Switch Fabric Slot 1 Slot 5 12. Switch Fabric Slot 2 Slot 6 13. Fan tray Slot 7 14. ESD connector Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 17: Fsx 1600 Chassis

    Sixteen half slots for interface modules • Eight slots for power supplies along the bottom of the card shelf The following figure shows the front of the FSX 1600 device. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 18 Hardware components FIGURE 3 FSX 1600 device Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 19 ESD wrist strap to ground yourself while handling and installing modules. DANGER For safety reasons, the ESD wrist strap should contain a series 1 megaohm resistor. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 20: Management Modules

    Each FSX 800 and FSX 1600 device requires one management module and as an option supports two management modules for full redundancy. Each management module occupies one half slot. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 21 FSX 1600 management modules are located in slots 17 and 18 along the edge of the device (refer to FSX 1600 chassis on page 17). The figure below shows the front panel of the IPv6 SX-FI-ZMR-XL and SX-FI-ZMR-XL-PREM6 management modules with no ports. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 22 The module is not the active management module. 10/100/1000 Copper Port LEDs on SX-FI-ZMR-XL and SX-FI-ZMR-XL-PREM6 modules only MGMT-Link Right-most LED above the port On (Green) 10/100/1000 Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 23 Port specifies the port number in the slot. Range is from 1 to 48 depending on the interface module. This example shows how to specify port 2 in slot 1: Brocade (config) # interface ethernet 1/2 Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 24: Switch Fabric Modules

    TABLE 5 Interface modules Interface Module Part Number FSX 800 FSX 1600 Second Generation Interface Modules 24-port Gigabit Ethernet copper SX-FI624C without PoE 24-port Gigabit Ethernet copper SX-FI624P with PoE Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 25 Enhanced Hot Swap capability in software Release 03.2.00 and later supports this procedure for the FastIron SX 800 and FastIron SX 1600 device. Enhanced Hot Swap (that is, no CLI disable ) should be performed during a maintenance window.
  • Page 26 48-port 10/100/1000 Mbps (RJ45) Ethernet PoE interface module The 48-port 10/100/1000 Mbps Ethernet PoE interface module (SX-FI48GPP) uses two vertical half-slots in the FastIron SX 800 or 1600 device and is supported in IPv4-only and IPv6-capable systems. The ports support automatic MDI or MDIX detection, and use auto-sensing and auto-negotiating to determine the speed (10, 100, or 1000 Mbps) and duplex mode (full-duplex or half-duplex) of the port at the other end of the link, and adjust the local port accordingly.
  • Page 27 PoE capability, or upgrade your existing 24-port Gigabit Ethernet Copper module by installing a PoE daughter card. To run PoE on your system, you must also install at least one 48-volt power supply. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 28 The front panel of the 24-port Gigabit Ethernet copper module includes 24 LEDs (top) that indicate the status of each port, and 24 LEDs (bottom) that indicate the PoE status. NOTE The PoE LEDs work only when PoE is enabled on your device. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 29 2. Port 2 14. Port 14 The front panel includes the following control features: • 24 10/100/1000 copper ports • 24 LEDs for port status • 24 LEDs for PoE status Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 30 SFP) Multisource Agreement (MSA)-compliant transceivers. The ports support 100 and 1000 fiber mini-GBICs. There are different part numbers available for the second (SX-FI624HF) and third generation (SX-FI-24HF) modules and they cannot be intermixed in release 08.0.00 and higher. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 31 To enable support for 100BaseFX, you must enter the CLI command 100-fx at the interface level of the CLI. For CLI command details, refer to the section "Enabling and Disabling Support for 100BaseFX" in the FastIron Ethernet Switch Administration Guide. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 32 The port is not transmitting or receiving traffic. LEDs for Third Generation 2-Port 10-Gigabit Ethernet module The 10 Gbps ports provide status information using the LEDs listed below. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 33 FIGURE 14 Third Generation 8-port 10-Gigabit Ethernet interface module The 10 Gbps ports provide status information using the LEDs listed in the table below. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 34: Network Interfaces

    100Base-BX M-FBXD or M-FBXU 100Base-FX M-FX, M-FXB1, or M-FXB2 100Base-FX-IR M-FX-IR 100Base-FX-LR M-FX-LR 100Base-FX-SR M-FX-SR 100Base-TX (copper only) M-TX 10GBase-1310-MMF 1310-MMF 10GBase-CX4 XG-CX4 10GBase-ER XG-ER 10GBase-LR XG-LR 10GBase-SR XG-SR Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 35: Power Supplies

    The following information applies to PoE power supplies: • The SX-ACPWR2500-PoE requires 220-volt input. • Because the SX-ACPWR2500-PoE powers up to 146 class 3 PoE ports, the SX-ACPWR-PoE is not sufficient as a backup power supply. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 36 The 52- 54-volt PoE power supplies provide power to the PoE daughter card, and ultimately to PoE power-consuming devices. The number of PoE power-consuming devices that one 52- 54-volt power supply can support depends on the Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 37 PoE+ ports it can support based on the number of PoE+ power supplies installed. PoE+ ports are enabled based on their priority settings. The system reserves the maximum configured power per PoE+ enabled port, even if the PoE+ power-consuming device is drawing less power. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 38 In the FSX 1600 device, the system power supplies occupy slot numbers 1 - 4 in the top row with the redundant supplies in slot numbers 3 and 4. The PoE power supplies occupy slot numbers 5 - 8 in the bottom row. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 39 The figure below shows a side-by-side comparison of the SX-ACPWR-SYS replacement power supply and the original power supply. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 40 The manufacturing part numbers are inscribed on the labels affixed to the top of the power supplies. In addition, the manufacturing part numbers for all installed power supplies are displayed in the output of the show chassis command. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 41: Power Supply Leds

    If this occurs and the AC OK (AC power supply) or DC IN (DC power supply) LED is Green, then there is a problem with the power supply and it must be replaced. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 42 After a power loss, if the system is left with less than the minimum number of power supplies required for normal operation, the system will be left in an unknown state. At this point, manual recovery is required (i.e., restore power and power cycle the device). Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 43: Cooling System

    The cooling system is contained within the system fan tray assembly and modules. The following components comprise the cooling system: • The FSX and FSX 800 each have six four-speed fans. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 44: Built-In Mounting Brackets

    The following figure identifies the slots where you can install modules and power supplies as well as the electrostatic discharge (ESD) connector, into which you can plug an ESD wrist strap to ground yourself while handling and installing modules. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 45 18. Management slot 18 Interface slot 8 19. Switch fabric slot 1 Interface slot 9 20. Switch fabric slot 2 10. Interface slot 10 21. ESD ground connector 11. Interface slot 11 Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 46 Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 47: Installing Fastiron Sx Devices

    The procedures in this manual are for qualified service personnel. NOTE Information about configuring IP addresses and connecting a FastIron SX chassis device to other network devices is covered in the “Connecting Network Devices and Checking Connectivity” section. Unpacking the system FastIron SX devices ship with the following items.

  • Page 48: Installation Precautions

    The mark is your assurance that the power cord can be used safely with the device. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 49 The POE power supply is designed exclusively for use with the FastIron X Series POE devices. The power supply produces extensive power to support 802.3af applications. Installing the power supply in a device other than the FastIron X Series POE will cause extensive damage to your equipment. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 50: Preparing The Installation Site

    You must remove these screws before installing the chassis. The figure below shows the location of the screws. To perform this task, you need a #2 Phillips-head screwdriver. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 51: Installing The Chassis In A Rack

    For each FastIron X Series that you install in a rack, you must provide four mounting screws with which to secure the chassis. To mount the chassis in a rack using the built-in mounting brackets, perform the following tasks. Determine the position of each chassis in the rack. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 52 Do not secure the screws completely; leave approximately 1/4 inch of clearance between the back of the screw head and the rack. FIGURE 22 Positioning two or four mounting screws in a rack. Keyhole slots Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 53: Installing Mounting Brackets On The Fsx 1600 Chassis

    Mount the brackets as shown in the figure below. Since the brackets are identical, you must rotate one bracket 90 degrees to fit on the opposite side from the first bracket. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 54 FIGURE 24 Installing the mounting brackets on an FSX 1600 chassis. Repeat Step 2 through Step 6 of the “Installing the chassis in a rack” task to install the FSX 1600 chassis in the rack. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 55: Removing The Slot Panels

    - Install in slot 8, fills slots 6 and 8 - Install in slot 6, fills slots 6 and 8 - install in slot 11, fills slots 11 and 13 Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 56 Each module occupies the equivalent of two slots, so plan your installation accordingly. See the fifth and sixth figure below. Fold the ejectors towards the center of the module to fully seat the module in the backplane. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 57 Use the #2 Phillips-head or flathead screwdriver to tighten the screws on each side of the module faceplate. The following illustrations show placement of management and interface modules in a FastIron X Series device. FIGURE 25 Installing a management module in the FSX 800 chassis. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 58 Installing management and interface modules FIGURE 26 Installing a management module in the FSX 1600 chassis. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 59 Installing management and interface modules FIGURE 27 Installing an interface module in the FSX 800 chassis. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 60 Installing management and interface modules FIGURE 28 Installing an interface module in the FSX 1600 chassis. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 61 Installing management and interface modules FIGURE 29 Installing an SX-FI48GPP POE+ interface module in an FSX 800 device Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 62: Attaching A Management Station

    NOTE The management network into which you can connect a Gigabit Ethernet port must be separate and isolated from the network over which user packets are switched and routed. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 63: Attaching A Pc Or Terminal To The Console Port Or 10/100/1000 Copper Port

    The mark is your assurance that the power cord can be used safely with the device. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 64: Power Cords

    The figure below shows the power plug configuration for the male and female end of the cable for the SX-ACPWR-SYS and SX- ACPWR-POE power supplies. The power cord is 2.5 meters in length. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 65 The figure below shows the power plug for the SX-ACPWR2500-POE power supply. FIGURE 32 AC power cable plug for SX-ACPWR2500-POE power supply The figure below shows the DC connector for the SX-DCPWR-SYS and SX-DCPWR-POE power supplies. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 66: Power Source Interruptions

    48 RTN Lead AWG Wire Positive Terminal Screw Terminal Screw Cover Power source interruptions The table below shows how the FastIron chassis protects against power surges and power drops. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 67: Connecting Ac Power To The Chassis

    At the rear of the chassis, locate the power receptacles on the power supplies. Lift the cord-retainer and connect a Brocade-supplied AC power cord to the power supply. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 68 Powering on the system Snap the cord-retainer over the power plug to hold it in place. FIGURE 34 Connecting the AC power cord on an FSX 800 device Cord retainer Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 69 Powering on the system FIGURE 35 Connecting the AC power cord on an FSX 1600 device. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 70: Connecting Dc Power To The Chassis

    To perform this task, you need the following items: • Flathead screwdriver • Phillips-head screwdriver • #6 AWG wire (grounding wire) • #8 AWG wire (input wire) • Crimping tool Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 71 Crimp #6 AWG ground wire and connect it to the ground position on the chassis. The ground position is located on the side or rear of the chassis next to the ground symbol. FIGURE 36 Chassis ground on FXS 800 device. Ground Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 72 FIGURE 37 Power lugs and cover screws Screws holding power lugs Screws holding transparent cover Use a Phillips-head screwdriver to remove the power lugs. Refer to the second figure below. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 73 Crimp #8 AWG input wire into the power lugs and reconnect the lugs to the power supply unit. Refer to the two figures below. FIGURE 38 Power supply wire #8 AWG power supply wire This equipment installation must meet NEC/CEC code requirements. Consult local authorities for regulations. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 74 If it is amber or OFF, the power supply is not providing power to the components. The ALM LED should be OFF. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 75: Verifying Proper Operation

    You can do the following: • Verify that the connection to the other device has been properly made. Also, make certain that the other device is powered on and Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 76 You can use the CLI. If you have configured an IP address on the device, you also can use the Web Management Interface or Brocade Network Advisor. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 77 • Make sure that the DC power source is 48VDC @ 30 A. • Make sure that the power source has power. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 78: Displaying The Module Status

    If you do not see this prompt, complete the following steps. Make sure the cable is securely connected to your PC or terminal and the Console port or Ethernet port. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 79 For more information, refer to Installing management and interface modules on page 55. • DISABLED - The module is not up and running. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 80 Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 81: Connecting Network Devices And Checking Connectivity

    User EXEC - The level you enter when you first start a CLI session. At this level, you can view some system information but you cannot configure system or port parameters. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 82: Recovering From A Lost Password

    Start a CLI session over the serial interface to the Brocade device. Reboot the device. While the system is booting, before the initial system prompt appears, enter b to enter the boot monitor mode. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 83: Configuring Ip Addresses

    If you accidentally do erase the configuration on a configured system, enter the write memory command to save the running configuration to the startup-config file. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 84 Access the configuration level of the CLI by entering the following command. Privileged EXEC Level. device# configure terminal Global CONFIG Level. device(config)# Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 85: Ipv6 Devices

    If you accidentally do erase the configuration on a configured system, enter the write memory command to save the running configuration to the startup-config file. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 86 If you accidentally do erase the configuration on a configured system, enter the write memory command to save the running configuration to the startup-config file. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 87: Connecting Network Devices

    1000Base-T ports. Therefore, a crossover cable may not be required; a straight-through cable may work as well. For more information about this feature, refer to the FastIron Ethernet Switch Administration Configuration Guide. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 88: Connecting To Workstations, Servers, Or Routers

    Straight-through UTP cabling is required for direct UTP attachment to workstations, servers, or routers using network interface cards (NICs). Fiber cabling with LC connectors is required for direct attachment to Gigabit NICs or switches and routers. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 89: Connecting A Network Device To A Fiber Port On The Brocade Device

    Put on the ESD wrist strap and ground yourself by inserting the plug into the ESD connector located in the lower right corner of the chassis front. Remove the module from the protective packaging. If necessary, remove the metal cover from the port on the interface module control panel. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 90: Automatic Mdi Or Mdix Detection

    The CX4 transceiver requires a 15 meter CX4-grade cable with 24 or 26 American Wire Gauge (AWG). This cable can be purchased from Brocade. Refer to part number CAB-CX4-0050 when ordering. See the second figure below. NOTE The CX4 transceiver is not hot-swappable. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 91 Connecting network devices FIGURE 42 CX4 transceiver CX4 transceiver FIGURE 43 CX4 transceiver cable CX4 transceiver cable Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 92: Testing Network Connectivity

    If you are not certain, remove the two cable connectors from the port connector and reinsert them in the port connector, reversing their order. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 93: Troubleshooting Network Connections

    To resolve problems that may arise with network connections: • For the indicated port, verify that both ends of the cabling (at the Brocade device and the connected device) are snug. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 94: Support For Digital Optical Monitoring

    Console messages and syslog messages are sent when optical operating conditions fall below or rise above the XFP or SFP manufacturer’s recommended thresholds. For details about this feature and how to configure it, refer to the FastIron Ethernet Switch Administration Configuration Guide. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 95: Managing The Chassis And Modules

    Speed 4: 50<----->80 deg-C (shutdown) Rule 2/3 (LINE CARDS THERMAL PLANE): Speed 1: NM<----->57 deg-C Speed 2: 48<----->58 deg-C Speed 3: 49<----->59 deg-C Speed 4: 50<----->80 deg-C (shutdown) Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 96 9 Temperature: 34.5 deg-C Slot 10 Temperature: 41.0 deg-C cont’d on next page... cont’d from previous page... Slot 11 Temperature: 40.0 deg-C Slot 12 Temperature: 46.0 deg-C Slot 13 Temperature: 42.0 deg-C Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 97 Fan 1 - This is Fan A and is the right-most fan in the rear of the chassis. • Fan 2 - This is Fan B and is the right-most fan in the rear of the chassis. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 98 On the FSX 800 and FSX 1600, the management modules are in slots 9 and 10 and the switch fabric modules are SF 1 and SF 2 . Other information Boot PROM MAC The MAC address of the chassis. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 99: Managing The Cooling System

    By default, the Brocade device polls the chassis every 60 seconds for temperature data. You can change this interval using the CLI command chassis poll-time . Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 100 If the temperature of any thermal plane exceeds the high threshold for the high speed and remains above the threshold for five minutes, the system automatically shuts down to prevent damage. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 101 (72 ° C) for the medium-high speed. Fan Speed Low Temperature Threshold High Temperature Threshold High 67 ° C 82 ° C Medium-high 57 ° C 72 ° C Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 102 The following shows an example warning message. !!! Temperature of SWITCH FABRIC CARDS THERMAL PLANE is over shutdown level, system is going to be shutdown in 300 seconds !!! Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 103: Monitoring The Cooling System

    The show chassis command displays the temperature reading of each thermal plane, as shown in the following examples. This following shows an example output. device# show chassis Fan controlled temperature: Rule 1/2 (MGMT CARDS THERMAL PLANE): 53.0 deg-C... Rule 2/2 (LINE CARDS THERMAL PLANE): 59.0 deg-C... Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 104 This section describes how to view the system log. If you have configured the system to use a Syslog server, refer to the documentation for the server or receiver. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 105: Displaying The Syslog Configuration And Static And Dynamic Buffers

    The total number of messages that have been logged since the software was loaded. level code The message levels represented by the one-letter codes. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 106: Static And Dynamic Buffers

    Configuration read error • Configuration write error • Memory read error • Memory write error For more information, refer to the “Using Syslog” chapter in the FastIron Ethernet Switch Administration Guide. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 107: Managing The Switch Fabric Modules (Fsx 800 And Fsx 1600 Only)

    If you enter the clear mac-address command without any parameters, the software removes all MAC entries. Use the mac-address variable to remove a specified MAC address from all VLANs. Specify the MAC address in the following format: HHHH.HHHH.HHHH. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 108 Ethernet interface module is installed. For the port parameter, enter the Ethernet port whose MAC address you want to remove. Use the vlannumber parameter to remove all MAC addresses for a specified VLAN. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 109: Using A Redundant Management Module

    After the active and standby modules are determined, both modules boot from the source specified for the active module. The active management module boots from the active management module’s flash memory. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 110: Management Module Switchover

    For information about how to remove and replace a management module, refer to Replacing a management module on page 120. This section explains how management module redundancy is affected when you remove and replace an active or standby management module. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 111: Switchover Implications

    When a switchover occurs, the system sends a Syslog message to the local Syslog buffer and also to the Syslog server, if you have configured the system to use one. In addition, if you have configured an SNMP trap receiver, the system sends an SNMP trap to the receiver. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 112: Management Module Redundancy Configuration

    Secondary - Contains the management module’s secondary IronWare image. The primary and secondary files also include a monitor file, which contains the management module’s Real Time Operating System (RTOS). Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 113 The boot code is synchronized between the two modules. The figure below shows how the files are synchronized between the active module and the standby module. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 114 Managing management module redundancy FIGURE 45 File synchronization between the active and standby modules Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 115: Manually Switching Over To The Standby Management Module

    Monitoring management module redundancy You can monitor the following aspects of management module redundancy: • The status of the management modules (if a module is the active or standby module) Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 116: Determining Management Module Status

    Wait - The module is awaiting boot information from the active management module. – Sync - The active module is currently synchronizing files between itself and the standby module. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 117: Displaying Temperature Information

    0d14h43m09s:N:powered On switch Fabric 0d14h43m01s:I:Mgmt CPU1 slot 9 failed 0d14h43m01s:I:System: Warm start 0d14h43m01s:I:SNMP: read-only community added by from session FastIron SX 800 This output shows that one switchover occurred. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 118 Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 119: Maintaining The Hardware

    Replacing the FSX 800 fan tray................................149 • Replacing the FSX 1600 fan assemblies............................152 • Replacing the air filter in the FastIron SX-1600..........................154 • Mean time between failure..................................155 Overview This chapter provides instructions for maintaining the FastIron X Series chassis hardware.

  • Page 120: Replacing A Management Module

    For safety reasons, the ESD wrist strap should contain a series 1 megaohm resistor. • A #2 Phillips-head or flathead screwdriver. To remove a management module from the chassis, perform the following tasks. Refer to the “Installation precautions.” Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 121: Installing A New Management Module

    Push the ejectors toward the center of the module. This action will fully seat the module in the backplane. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 122 Use a #2 Phillips-head or flathead screwdriver to tighten the two screws at either end of the management module’s front panel. FIGURE 46 Installing a management module in the FSX 800 chassis Management module Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 123 Replacing a management module FIGURE 47 Installing a management module in the FSX 1600 chassis Management module Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 124: Replacing A Switch Fabric Module (Fsx 800 And Fsx 1600 Only)

    An ESD wrist strap with a plug for connection to the ESD connector on the chassis front. DANGER For safety reasons, the ESD wrist strap should contain a series 1 megaohm resistor. • A #2 Phillips-head or flathead screwdriver. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 125 Push the ejectors toward the center of the module. This action will fully seat the module in the backplane. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 126 Use a #2 Phillips-head or flathead screwdriver to tighten the two screws at either end of the switch fabric module’s front panel. FIGURE 48 Installing a switch fabric module in the FSX 800 Switch Fabric module Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 127 Replacing a switch fabric module (FSX 800 and FSX 1600 only) FIGURE 49 Installing a switch fabric module in the FSX 1600 Switch Fabric module Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 128: Replacing An Interface Module

    Re-insertion of a line module less than 10 seconds after the removal of a line module may result in the line module not being properly recognized. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 129: Removing An Interface Module

    Push the ejectors in toward the center of the module. This action will fully seat the module in the backplane. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 130 FIGURE 50 Installing an interface module in the FSX 800 chassis Interface module Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 131: Disabling And Re-Enabling An Interface Module

    If you attempt to remove the management module while the chassis is powered on and running, all traffic being handled by the system will stop. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 132: Replacing A Copper Or Fiber Optic Module

    Put on the ESD wrist strap and ground yourself by inserting the plug into the ESD connector located in the lower right corner of the chassis front. Disconnect the copper or fiber cable connectors from the port connectors. Insert the protective covering into the port connectors. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 133: Installing A New Copper Or Fiber Optic Module

    An ESD wrist strap with a plug for connection to the ESD connector on the chassis. DANGER For safety reasons, the ESD wrist strap should contain a series 1 megaohm resistor. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 134: Cabling A Fiber Optic Module

    1, "power 2" indicates the power supply installed in slot 2, and so on. The two figures below show the power supply slot numbers. If the display indicates "Installed (Failed)" for any of the slots, the power supply installed in that particular slot has failed. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 135: Removing An Ac Power Supply

    FIGURE 52 Power supply placement in the FSX 800 FIGURE 53 Power supply placement in the FSX 1600 Removing an AC power supply You can order a new AC power supply from Brocade Communication Systems, Inc. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 136 Install a new power supply in the slot. For information about performing this task, refer to the “Installing a new power supply” section. Removing an original power supply The following illustration shows the original power supplies. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 137: Removing A Dc Power Supply

    You can order a new DC power supply from Brocade Communication Systems, Inc. The power supplies are hot swappable, which means they can be removed and replaced while the chassis is powered on and running. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 138 FIGURE 54 DC power supply Screws holding power lugs Screws holding transparent cover Use a Phillips-head screwdriver to remove each of the power lugs. Remove both wires from the power lugs. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 139: Installing A New Power Supply

    For an overview of replacement power supplies (part numbers 32014-xxx and 32016-xxx), refer to the “Replacement power supplies” section. To install a replacement power supply, you need a Phillips-head or flathead screwdriver. The following illustration shows the replacement power supplies. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 140 Be careful when closing the latch. Your fingers could get caught or pinched between the latch and the front of the power supply. When the power supply is fully seated, tighten the retaining screw as shown below. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 141 Installing or replacing a power supply Connect power to the chassis. Refer to the “Connecting AC power to the chassis” section. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 142 Installing or replacing a power supply FIGURE 55 Installing a replacement power supply Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 143: Connecting Ac Power To The Chassis

    AC power is supplied though an AC power cord that is installed at the rear of the chassis. At the rear of the chassis, locate the power receptacle where the power supplies have been installed. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 144: Connecting Dc Power To The Chassis

    You can use a DC power source for the Brocade chassis. This is supported through use of a DC to DC power supply. DC power must be supplied at 48 V and 30 A. To perform this task, you need the following items: • Flathead screwdriver • Phillips-head screwdriver • #6 AWG wire (grounding wire) Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 145 Use a flathead screwdriver to remove the two screws holding the transparent cover over the power supply lugs. The following illustration shows the location of the screws and lugs. Screws holding power lugs Screws holding transparent cover Use a Phillips-head screwdriver to remove each of the power lugs. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 146 Installing or replacing a power supply Crimp #8 AWG input wire into the power lugs and reconnect the power lugs to the power supply unit #8 AWG power supply wire Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 147 If it is amber or OFF, the power supply is not providing power to the chassis components. The ALM LED should be OFF. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 148: Verifying Proper Operation

    If this occurs and the AC OK (AC power supply) or DC IN (DC power supply) LED is Green, then there is a problem with the power Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 149: Displaying The Status Of The Power Supplies

    Put on the ESD wrist strap and ground yourself by inserting the plug into the ESD connector located in the lower right corner of the chassis front or use the ESD strap provided with the fan tray kit. Attach the copper tape end to a bare metal area on the chassis. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 150 The figure below shows the location of the screws. To perform this task, you need a #2 Phillips-head screwdriver. FIGURE 56 Removing the extra screws used for shipment Shipping screws Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 151 Be careful not to accidently insert your fingers into the fan tray while removing it from the chassis. The fan may still be spinning at a high speed. FIGURE 57 Removing the fan tray Fan Tray Latch Fan Tray Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 152: Replacing The Fsx 1600 Fan Assemblies

    Put on the ESD wrist strap and ground yourself by inserting the plug into the ESD connector located in the top right corner of the chassis front. Using the flathead screwdriver, loosen the four captive screws that secure the fan (marked "Fan A" or "Fan B") to the back of the chassis. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 153 Secure the fan to the chassis by tightening the four captive screws. Access the CLI, and enter the show chassis command to verify that both fans are operating normally. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 154: Replacing The Air Filter In The Fastiron Sx-1600

    If Brocade switches and routers are placed in operation in environments where dust or other airborne contaminants may be prevalent, air filters should be inspected annually and replaced if needed. Maintaining clean air filters ensures optimal airflow through the device. FIGURE 59 Air filter removal and replacement for FastIron SX-1600. Fan tray Filter Retainer...

  • Page 155: Mean Time Between Failure

    Mean time between failure To replace the air filter in the FastIron SX-1600, perform the following tasks. Loosen the captive fasteners in the front of the filter retainer. Pull the filter retainer away from the chassis as shown in the figure above.
  • Page 156 IPv4 management module with no ports 40 ° C 534,522 Interface Modules 24-port Fiber with no optics 40 ° C 348,204 24-port Fiber with 24 optics 40 ° C 110,328 Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 157 2-port 10-Gigabit Ethernet with no optics 40 ° C 464,938 2-port 10-Gigabit Ethernet with one XFP 40 ° C 421,084 2-port 10-Gigabit Ethernet with two XFPs 40 ° C 384,789 Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 158 Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 159: Brocade Fastiron Sx Series Technical Specifications

    FastIron SX 1600 - Two five-speed fans in the rear of the device Cooling FastIron SX 800 - Six four-speed fans FastIron SX 1600 - Six four-speed fans and two five-speed fans in the rear of the device System architecture Nonblocking architecture...

  • Page 160: Other

    2.0 G sine, 1.4 gms random, 5 to 500 Hz Airflow 762 CFM Heat dissipation 4874 BTU/hr Operating noise 50 dB maximum for power supplies with the following manufacturing part numbers: • 32014-xxx Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 161: Power Supply Specifications (Per Psu)

    Power consumption (maximum configuration) Maximum power consumption in a fully loaded, functional chassis: • FastIron SX 800 - 1200 W • FastIron SX 1600 - 2050 W Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 162: Serial Port Specifications (Db9)

    Serial port specifications (protocol) Parameter Value Baud 9600 bps Data bits Parity None Stop bits Flow control None Memory specifications Memory Size First- and second-generation 512 MB Third-generation 4 GB Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 163: Regulatory Compliance (Emc)

    30/2011/TT-BCT - Vietnam circular • SJ/T 11363-2006 Requirements for Concentration Limits for Certain Hazardous Substances in EIPs (China) • SJ/T 11364-2006 Marking for the Control of Pollution Caused by EIPs (China) Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 164 Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 165: Additional Pinout And Signaling Information

    Pinout information for the console serial RJ45 management port and the 10, 100, and gigabit port is provided in the following sections. Console (serial RJ45) management port pinouts TABLE 29 Console serial RJ45 management port pinouts Pin number Definition Notes UART0_TX Console Port UART0_RX Console Port Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 166: 10/100 And Gigabit Port Pinouts

    10/100 and gigabit port pinouts 10/100 and gigabit port pinouts FIGURE 60 Pin assignment and signalling for 10/100Base-TX and 1000Base-T ports Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 167: Cable Specifications

    2000 (2 km) module 100Base-FX-IR LC connector for SFP 1310 up to 15000 (15 km) module 100Base-FX-LR LC connector for SFP 1310 up to 40000 (40 km) module Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 168 2 - 300 10GBase-ZR LC connector for XFP 1550 nm up to 80000 (80 km) module 10GBase-ZRD LC connector for XFP 1530.33 - 1561.42 up to 80000 (80 km) module Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 169: Regulatory Statements

    BSMI statement (Taiwan) Warning: This is Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 170: Canadian Requirements

    This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations, ICES-003 Class A. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. China CC statement Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 171: Europe And Australia (Cispr 22 Class A Warning)

    This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance might arise. When such trouble occurs, the user might be required to take corrective actions. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 172 Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 173: Caution And Danger Notices

    VORSICHT Lassen Sie keine Werkzeuge im Chassis zurück. MISE EN GARDE Ne laissez jamais d'outils à l'intérieur du châssis PRECAUCIÓN No deje nunca herramientas en el interior del chasis. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 174: Electrical Cautions

    PRECAUCIÓN Use un circuito derivado separado para cada cordón de alimentación, con lo que se proporcionará redundancia en caso de que uno de los circuitos falle. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 175 Se entiende como área de acceso restringido un lugar al que solo puede acceder personal de servicio mediante el uso de una herramienta especial, llave y cerrojo u otro medio de seguridad similar, y que esté controlado por la autoridad responsable de esa ubicación. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 176 Das POE+ Stromnetz hat für die FastIron X Series POE+ Geräte ausschießlich aufgezeichnet. Dieses Stromnetz erzeugt umfassend Starkstrom zur Bestätigun von 802.3at Anwendungen. Ihr Anlage beschädigt wird, wenn das Stromnetz in Geräte anders als FastIron X Series POE+ einbauen wird. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 177 Für ein Brocade Wechselstromsystem ist ein Erdleiter von mindestens 6 AWG (amerikanische Norm für Drahtquerschnitte) zu verwenden. An einem Ende des Erdleiters sollte ein geprüfter gecrimpter Anschluss (mit Chassis bereitgestellt) angebracht Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 178: Danger Notices

    A Danger statement indicates conditions or situations that can be potentially lethal or extremely hazardous to you. Safety labels are also attached directly to products to warn of these conditions or situations. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 179: General Dangers

    Courant de fuite élevé. Mise à la terre obligatoire avant la connexion de l'alimentation. PELIGRO Alta tensión al tacto. La conexión a tierra es esencial antes de conectar la alimentación. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...
  • Page 180 GEFAHR Stellen Sie sicher, dass die Stromkreise ordnungsgemäß geerdet sind. Benutzen Sie dann das mit dem Gerät gelieferte Stromkabel, um es an die Srromquelle anzuschließen. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 181: Dangers Related To Equipment Weight

    DISPOSITIFS, DEUX PERSONNES MINIMUM SONT NÉCESSAIRES. PELIGRO Un chasis muy concurrido es muy pesado. SE REQUIEREN DOS O MÁS PERSONAS CUANDO SE VAYA A ALZAR, MANEJAR O MONTAR ESTE DISPOSITIVO. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

  • Page 182: Laser Dangers

    Alle Glasfaser-Schnittstellen verwenden Laser der Klasse 1. DANGER Toutes les interfaces en fibres optiques utilisent des lasers de classe 1. PELIGRO Todas las interfaces de fibra óptica utilizan láser de clase 1. Brocade FastIron SX Series Chassis Hardware Installation Guide Part Number: 53-1003613-04...

Table of Contents
