2 Flatpack2 Rectifier & Converter Modules
16
User's Guide Flatpack2 Rectifier & Converter Modules,

Flatpack2 Rectifier 380VDC, 2500W HE - (Data Centres)

Part number 241119.825. High efficiency rectifier for High
Voltage DC power supply facilities in data centres, central
offices, HVDC UPS, etc.
This module enables implementing large systems of up to
2.4MW, e.g. stacking 48 rectifier cabinets controlled by a
single Smartpack2 control system.
For technical data, read chapter "Specifications Flatpack2
Rectifier 380VDC, 2500W HE - (Data Centres)", page 35.

DC/DC Converters

Flatpack2 DC/DC Converter 1350W, 18-75VDC, 24VDC

Part number 241115.600. This flexible, wide input (18-
75VDC) DC/DC converter may be integrated in telecom and
industrial applications to supply 24VDC loads.
Large 2kW-1MW Flatpack2 power systems can also be
implemented using the DC/DC converters together with
Flatpack2 AC/DC rectifiers to supply galvanic isolated multi-
voltage loads. The system's galvanic isolated CAN buses
enable monitoring
rectifiers from the same main controller.
For technical data, read chapter "Specifications Flatpack2
DC/DC Converter 1350W, 18-75VDC, 24VDC and 48VDC",
page 36.

Flatpack2 DC/DC Converter 1350W, 18-75VDC, 48VDC

Part number 241115.602. This flexible, wide input (18-
75VDC) DC/DC converter may be integrated in telecom and
industrial applications to supply 48VDC loads, otherwise is
similar to "Flatpack2 DC/DC Converter 1350W, 18-75VDC,
24VDC".
For technical data, read chapter "Specifications Flatpack2
DC/DC Converter 1350W, 18-75VDC, 24VDC and 48VDC",
page 36.
and controlling the converters and
350002.013, 8v1-2013-08
