  • Page 1 User's Guide FlatpackS Modules Rectifiers and Supervision FlatpackS DC Power Supply Systems Anatel Homolgation Numbers Rectifier 0863-15-2298 Power System 0864-15-2298...
  • Page 2 WARNING: The installer/user is responsible for ensuring that the DC power system is not damaged by current surges, over-voltages, etc. caused by external transients, lightning, electrostatic discharge, etc. To avoid damage and obtain the expected system reliability, it is mandatory to always install SPDs in Eltek’s power Current Surge supply systems.
  • Page 3 Eltek. Copyright ©: Eltek, 2015 Safety Precautions The equipment described in this manual must only be operated by Eltek  personnel or by persons who have attended a suitable Eltek training course The equipment represents an energy hazard and failure to observe this ...

  • Page 4: Table Of Contents

    Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Table of Contents Introduction About this Guide ......................5 System Diagrams ...

  • Page 5: Introduction

    1. Introduction The FlatpackS rectifier module is a powerful and cost-effective power supply used in Eltek’s FlatpackS DC power systems. About this Guide This booklet provides users of FlatpackS DC power systems with the required information to install and operate the FlatpackS rectifier modules.

  • Page 6: Flatpacks Rectifier & Supervision Modules

    19” power shelves (4 modules across). A wide range of features are implemented in the FlatpackS module, as mentioned below. Key Features  Highest efficiency in minimum space Eltek Resonant topology makes the module efficiency industry leading, and Label contributes to the module’s ultra-compact dimensions.

  • Page 7: Installation Of Flatpack2 Modules

    Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. 3. Installation of Flatpack2 Modules Installing Rectifiers, Controller and Blind Panels CAUTION: The rectifiers may be warm, you may hand-carry them by their handle.

  • Page 8: Mounting Or Removing Blind Panels

    Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Mounting or Removing Blind Panels Always mount blind panels in unused Flatpack S rectifiers’ and Smartpack S controllers’...

  • Page 9: Accessing The Controller's Ethernet Port

    Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Lock the controller by using a screwdriver to turn the locking screw ¼ of a turn counter clockwise to the locked position (pos 1).

  • Page 10: Terminals And Pin-Out Locations, Smartpack S Controller

    Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Terminals and Pin-out Locations, Smartpack S Controller Location of Connector, Communication Ports “Connection Drawing”...

  • Page 11: Connection Drawing

    Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Connection Drawing Use this drawing as a customer connection reference for all cabling. You find the exact location of connection terminals, plugs, DIP switches, jumpers, etc.
  • Page 12 Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. All the 6 inputs may be configured as Auxiliary Switch (open/close, pull-up or pull-down), as temperature sense inputs with external NTC sensors, or as Clock inputs.

  • Page 13: Operation

    Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. 4. Operation Front Panel — Flatpack S Rectifier Module The Power LED is OFF (mains unavailable), Flashing (controller accessing information) or ON (powered).

  • Page 14: Graphical Display

    Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Graphical Display The Graphical Color Display — 2.2” TFT — is either in Status Mode (displays the system’s status) or in Menu Mode (displays the menu structure).

  • Page 15: Software Menus

    Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Software Menus The Smartpack S-based system’s functionality is accessed via a network of software menus and submenus , enabling you to configure and control the whole power system from the controller’s front panel.

  • Page 16: Controller Access - Via Stand-Alone Pc

    You can access the Smartpack S controller directly from a stand-alone computer, or via a Local Area Network (LAN) if available. Each controller is shipped with a unique Eltek MAC address stored inside the controller and marked on the controller’s label, and with the fixed IP address <192.168.10.20>.

  • Page 17: Technical Specifications

    Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. 5. Technical Specifications Model 48/1000 HE 48/1800 HE Part number 241122.105 241122.125...
  • Page 18 Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. Erro! Use a guia Página Inicial para aplicar Heading 1 ao texto que deverá aparecer aqui. input only allowed when up-stream breaker rated applicable input voltage maximum...
