User's Guide Flatpack2 Rectifier & Converter Modules,
Rectifiers — Output Voltage Lower than 60VDC

Flatpack2 Rectifier 24V, 1800W HE

Part number 241115.205. For description, refer to chapter
"Flatpack2 Rectifier 48V, 2000W HE", page 11. For technical
data, read chapter "Specifications Flatpack2 Rectifier 24V,
1800W HE", page 23.

Flatpack2 Rectifier 24V, 2000W

Part number 241115.200. Refer to chapter "Specifications
Flatpack2 Rectifier 24V, 2000W", page 24.

Flatpack2 Rectifier 24V, 2000W WOR

Part number 241115.250. This rectifier's Wide Output voltage
Range is optimized for charging any type of batteries.
Refer to chapter "Specifications Flatpack2 Rectifier 24V,
2000W WOR" on page 25.

Flatpack2 Rectifier 48V, 1800W

Part number 241115.001. Refer to chapter "
Specifications Flatpack2 Rectifier 48V, 1800W" on page 26

Flatpack2 Rectifier 48V, 2000W

Part number 241115.100. Refer to chapter "Specifications
Flatpack2 Rectifier 48V, 2000W" on page 27
P (W)
2000
1350

Flatpack2 Rectifier 48V, 2000W HE

Part number 241115.105. The combination of innovative
design, efficiency and reliability makes the Flatpack2 HE
rectifier stands out. With an efficiency of up to 96.5%, the
losses have been reduced by 50% compared to the current
industry standard.
Also, the Flatpack2 HE rectifier has an extremely high
efficiency at low load, which historically has been a drawback
with most modern soft switching technologies.
Refer to chapter "Specifications Flatpack2 Rectifier 48V,
2000W HE" on page 28.
2 Flatpack2 Rectifier & Converter Modules
Flatpack2 Rectifier 48V, 2000W
Operating Temperature
Output voltage vs. Temperature
+45 +75 Temp (°C)
350002.013, 8v1-2013-08
11
