Port Mirroring Feature Guide for EX9200 Switches
Related
Documentation

Examples: Layer 2 Port Mirroring at Multiple Levels of the Chassis

34
To disable the definition of a particular named instance of Layer 2 port mirroring, include
the statement at the
disable
hierarchy level:
instance-name]
[edit]
forwarding-options {
port-mirroring {
...optional-configuration-of-the-global-instance-of-layer-2-port-mirroring...
instance {
port-mirroring-instance-name {
disable; Disables this named instance of Layer 2 port mirroring.
...definition-of-a-named-instance-of-layer-2-port-mirroring...
}
}
}
}
To disable the global instance and all named instances of Layer 2 port mirroring, include
the
disable-all-instances
hierarchy level:
[edit]
forwarding-options {
port-mirroring {
disable-all-instances; Disables all instances of Layer 2 port mirroring.
...optional-configuration-of-the-global-instance-of-layer-2-port-mirroring...
instance {
port-mirroring-instance-name {
...definition-of-a-named-instance-of-layer-2-port-mirroring...
}
}
}
}
Understanding Layer 2 Port Mirroring on page 3
Layer 2 Port Mirroring Global Instance on page 9
Layer 2 Port Mirroring Named Instances
Displaying Layer 2 Port-Mirroring Instance Settings and Status on page 95
On an MX Series router or on an EX Series switch, you can apply named instances of
Layer 2 port mirroring at the FPC or DPC level of the chassis or at the PIC level of the
chassis. However, you can configure (and implicitly apply) only one global instance of
Layer 2 port mirroring to the entire chassis.
Layer 2 Port Mirroring at the FPC Level on page 35
Layer 2 Port Mirroring at the PIC Level on page 35
Layer 2 Port Mirroring at the FPC and PIC Levels on page 35
[edit forwarding-options port-mirroring instance
statement at the
[edit forwarding-options port-mirroring]
