Sample Output
show chassis pic fpc-slot pic-slot
Copyright © 2016, Juniper Networks, Inc.
Chapter 13: Operational Commands: Packet Forwarding Engine Components
Table 10: show chassis pic Output Fields (continued)
Field Name
PIC Port Information
(Next-Generation
SONET/SDH SFP)
PIC port information
(MX104 router)
Multirate Mode
Channelization
Administrative State
Operational State
user@host> show chassis pic fpc-slot 2 pic-slot 0
PIC fpc slot 2 pic slot 0 information:
Type
ASIC type
State
PIC version
Uptime
PIC Port Information:
Port Cable
Number Type
0 GIGE 1000EX
1 GIGE 1000EX
Field Description
Port-level information for the next-generation SONET/SDH SFP
PIC.
Port—Port number.
Cable type—Type of small form-factor pluggable (SFP) optical
transceiver installed.
Fiber type—Type of fiber: SM
Xcvr vendor—Transceiver vendor name.
Xcvr vendor part number—Transceiver vendor part number.
Wavelength—Wavelength of the transmitted signal.
Next-generation SONET/SDH SFPs use 1310 nm.
Port-level information for the PIC.
Port—Port number
Cable type—Type of optical transceiver installed.
Fiber type—Type of fiber. SM is single-mode.
Xcvr vendor—Transceiver vendor name.
Xcvr vendor part number—Transceiver vendor part number.
Wavelength—Wavelength of the transmitted signal.
Xcvr Firmware—Firmware version of the transceiver.
Rate-selectabilty status for the MIC:
Indicates whether channelization is enabled or disabled on the
DS3/E3 MIC.
Indicates the administrative state of the PIC. Possible values are:
In Service (Default) and Out of Service.
Indicates the operational state of the PIC. Possible values are:
Normal and Fault.
10x 1GE(LAN), 1000 BASE
H chip
Online
1.1
1 day, 50 minutes, 58 seconds
Xcvr
Vendor Name
FINISAR CORP.
FINISAR CORP.
(single-mode) or MM (multimode).
or .
Enabled Disabled
Xcvr Vendor
Part Number
FTRJ8519P1BNL-J3
FTRJ-8519-7D-JUN
393
