Lock Connections Example 2

The jumpers on the rear of the door station offer different
types of release modes for alternative applications
dependent on the jumper link settings. LOCK1 options;
N.O
Volt-free
J3 J1 J2
3
2
1
Image of
N.C
jumper link
Volt-free
J3 J1 J2
3
2
1
N.O
12vDC300mA
MAX
J3 J1 J2
3
2
1
Jumper 1 gives the option to set the release time;
5
sec.
8
APKITG Manual.indd 8
3
sec.
The door station has a secondry switch. LOCK2 options;
N.O
Volt-free
J3 J1 J2
3
2
1
Image of
N.C
jumper link
Volt-free
J3 J1 J2
3
2
1
N.O
12vDC300mA
MAX
J3 J1 J2
3
2
1
Please refer to the operation guide for release instructions
