Lock Connections Example 1

Electro-magnetic lock
_
+
4
3
NC
+
_
+
_
System Wiring
Electronic lock
Lock -release time
N.C for Electro-magnetic lock
N.O for Electronic lock
At the rear of the door station
LOCK1
ensure that the jumper links cover pins
1 and 2, on both J3 and J2 positions
VCC
J3
3
BUS
2
1
J1 J2 J1
Image of
jumper link
