IAI GO-2400M-USB User Manual

2.35m digital progressive scan monochrome and color camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Thank you for purchasing this product.
Be sure to read this manual before use.
This manual includes important safety precautions and instructions on
how to operate the unit. Be sure to read this manual to ensure proper
operation.
© 2017 JAI

User Manual

GO-2400M-USB
GO-2400C-USB
2.35M Digital Progressive Scan
Monochrome and Color Camera
Document Version: 1.0
GO-2400-USB_Ver.1.0_Mar.2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GO-2400M-USB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IAI GO-2400M-USB

Summary of Contents for IAI GO-2400M-USB

  • Page 1: User Manual

    User Manual GO-2400M-USB GO-2400C-USB 2.35M Digital Progressive Scan Monochrome and Color Camera Document Version: 1.0 GO-2400-USB_Ver.1.0_Mar.2017 Thank you for purchasing this product. Be sure to read this manual before use. This manual includes important safety precautions and instructions on how to operate the unit. Be sure to read this manual to ensure proper operation.

  • Page 2: Table Of Contents

    GO-2400M-USB / GO-2400C-USB Contents Notice ................3 Shading Correction .............32 Warranty ...............3 Flat Shading ............32 Color Shading (GO-2400C-USB only) ....33 Certifications ..............3 Warning ................3 To use the shading correction function ....33 Usage Precautions ............6 Binning Function ............33 Features ................7 ROI (Regional Scanning Function) ......34 ROI Settings ............34...

  • Page 3: Notice

    CE compliance As defined by the Directive 2004/108/EC of the European Parliament and of the Council, EMC (Electromagnetic compatibility), JAI Ltd., Japan declares that GO-2400M-USB and GO-2400C-USB comply with the following provisions applying to its standards. EN 61000-6-3 (Generic emission standard part 1)
  • Page 4 GO-2400M-USB / GO-2400C-USB Supplement The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera.
  • Page 5 GO-2400M-USB / GO-2400C-USB Supplement The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera.

  • Page 6: Usage Precautions

    GO-2400M-USB / GO-2400C-USB Usage Precautions Notes on cable configurations The presence of lighting equipment and television receivers nearby may result in video and audio noise. In such cases, change the cable configurations or placement. Notes on attaching the lens Avoiding dust particles When attaching the lens to the camera, stray dust and other particles may adhere to the sensor surface and rear surface of the lens.

  • Page 7: Features

    High frame rate The GO-2400M-USB and GO-2400C-USB are both capable of frame rates of up to 159 fps (8-bit format) for full 2.35-megapixel output. Even faster frame rates can be achieved when a smaller ROI (region of interest) is specified.

  • Page 8: Parts Identification

    GO-2400M-USB / GO-2400C-USB Parts Identification ② ③ ⑥ ① ④ ⑤ ⑥ 1 Lens mount (C-mount) Mount a C-mount lens, microscope adapter, etc. here. Before mounting a lens, be sure to refer to “Step 2: Connecting Devices” (page 12) and confirm the ™...
  • Page 9 GO-2400M-USB / GO-2400C-USB 4 DC IN / trigger IN connector (6-pin round) Connect the cable for a power supply (optional) or for DC IN / trigger IN here. HR-10A-7R-6PB (73) (Hirose Electric or equivalent) Input/ Pin No. Signal Description output DC IN +12 to +24 V±10%...
  • Page 10 GO-2400M-USB / GO-2400C-USB Recommended external output circuit diagram (reference example) Standard circuit diagram example JAI camera User side Userload User GO Series CAMERA (resistor/lamp/relay/etc) side side OUT f rom camera 330~ TLP109(TPR,E) HIROSE_6Pin_NO.3 or 4 2SC6033 180BS USER POWER2 220BS...

  • Page 11: Preparation

    GO-2400M-USB / GO-2400C-USB Preparation Preparation Process Step 1 Installing the Software (first time only) Install the software for configuring and controlling the camera (JAI SDK) on the computer.  Step 2 Connecting Devices Connect the lens, USB cable, AC adapter, computer, and other devices.

  • Page 12: Step 2: Connecting Devices

    GO-2400M-USB / GO-2400C-USB Step 2: Connecting Devices Connect the lens, USB cable, AC adapter, and other devices. Attach the lens in a clean environment to prevent dust from adhering to the unit. Camera body 3 USB cable 1 Lens 4 Computer...
  • Page 13 GO-2400M-USB / GO-2400C-USB Caution • The maximum performance of the camera may not be realized depending on the lens. • Attaching a lens with a mount protrusion of 9.1 mm or longer may damage the lens or camera. Note The following formula can be used to estimate the focal length.

  • Page 14: Step 3: Verifying The Camera's Network Connection Status

    GO-2400M-USB / GO-2400C-USB Step 3: Verifying the Camera’s Network Connection Status When power is supplied to the camera while the necessary equipment is connected, the power / trigger LED at the rear of the camera lights amber, and initialization of the camera starts.

  • Page 15: Configuring The Output Format

    Offset Y (vertical position) 0 (pixels) Pixel Format GO-2400M-USB: 8 Bit Monochrome GO-2400C-USB: 8 Bit Bayer RG ™ You can specify the image acquisition area. For details, see “ROI (Regional Scanning Function)” (page 34). Select the [Feature Properties] tab, and select the item you want to configure under [Image Format Control].

  • Page 16: Configuring Exposure And External Trigger Settings

    GO-2400M-USB / GO-2400C-USB Example: When changing [Pixel Format] Note Direct entry of numerical and text values is possible for some setting items. Configuring Exposure and External Trigger Settings Configure settings related to exposure control methods and trigger control. The factory settings are as follows. Change settings as necessary, according to the intended purpose or application.

  • Page 17: Control Via External Triggers

    GO-2400M-USB / GO-2400C-USB Control via External Triggers When Controlling the Exposure Time Using Specified Exposure Times Configure the settings as follows. Item Setting value / selectable range Trigger Selector (trigger operation) Frame Start Trigger Mode Trigger Source (trigger signal source)

  • Page 18: Control Without External Triggers

    GO-2400M-USB / GO-2400C-USB Set [Exposure Mode] to [Trigger Width] . When you select [Trigger Width], [Trigger Mode] will automatically be set to [On]. Set [Trigger Selector] to [Frame Start]. ([Frame Start] is the default setting.) If necessary, change the [Trigger Source] and [Trigger Activation] settings.

  • Page 19: When Not Controlling The Exposure Time

    Expand [Analog Control], and select the gain you want to configure in [Gain Selector]. • For the GO-2400M-USB, only [Analog All] (master gain) can be configured. • For the GO-2400C-USB, [Analog All] (master gain), [Digital Red] (digital R gain), and [Digital Blue] (digital B gain) can be configured individually.

  • Page 20: Adjusting The White Balance (Go-2400C-Usb Only)

    Expand [Analog Control], and select the black level you want to configure in [Black Level Selector]. For the GO-2400M-USB, only [Digital All] (master black) can be configured. For the GO-2400C-USB, [Digital All] (master black), [Digital Red] (digital R), and [Digital Blue] (digital B) can be configured individually.

  • Page 21: To Save User Settings

    GO-2400M-USB / GO-2400C-USB User memory Temporary memory User Set1 Current setting User Set2 values Save User Set3 Control Tool Note Changes to settings are not saved to the computer (Control Tool). ■ To save user settings Stop image acquisition. Expand [User Set Control], and select the save destination ([User Set1] to [User Set3]) in [User Set Selector].

  • Page 22: To Load User Settings

     2 × 1 × × × × ×     2 × 2 × × × × ×     *1 Operates only on the GO-2400M-USB *2 Operates only on the GO-2400C-USB — 22 —...

  • Page 23: Main Functions

    GO-2400M-USB / GO-2400C-USB Main Functions GPIO (Digital Input/Output Settings) The camera is equipped with GPIO (general-purpose input/output) functions for generating and using combinations of triggers and other necessary signals within the camera and of signals output from the camera to the system such as those used for lighting equipment control.

  • Page 24: Acquisition Control (Image Acquisition Controls)

    GO-2400M-USB / GO-2400C-USB Acquisition Control (Image Acquisition Controls) Perform operations and configure settings related to image acquisition in [Acquisition Control]. The following acquisition modes are available on the camera. Acquisition Mode Description Single Frame Acquire a single frame when the [Acquisition Start] command is executed.

  • Page 25: Maximum Frame Rate Period Formula

    GO-2400M-USB / GO-2400C-USB ■ Maximum frame rate period formula During continuous operation ([Frame Start] trigger is [Off] or [Exposure Mode] is [Off]) • Maximum frame rate of sensor output SensorFR = 1 / ((Height_s + 40) × Hperiod) • Maximum frame rate of USB 3.0 output bandwidth InterfaceFR = 3000 ×...

  • Page 26: Exposure Mode

    GO-2400M-USB / GO-2400C-USB Pixel Format H Period (μs) Pack Value 8 bit 4.8485 10 bit packed 6.2222 12 bit packed 6.2222 10 bit/12 bit 6.2222 Exposure Mode The following exposure modes are available on the camera. Exposure Mode Description Exposure control is not performed (free-running operation).

  • Page 27: When [Exposure Mode] Is [Timed]

    GO-2400M-USB / GO-2400C-USB ■ When [Exposure Mode] is [Timed] Example: When [Trigger Source] is set to [Line 5 - Optical In 1] and [OptIn Filter Selector] is set to [10 µs] • Trigger overlap: Off 次のトリガ Next trigger 次のトリガ無効 Next trigger disabled 入力可能...

  • Page 28: When [Exposure Mode] Is [Trigger Width]

    GO-2400M-USB / GO-2400C-USB ■ When [Exposure Mode] is [Trigger Width] Example: When [Trigger Source] is set to [Line 5 - Optical In 1] and [OptIn Filter Selector] is set to [10 µs] • Trigger overlap: Off 次のトリガ Next trigger 次のトリガ無効...

  • Page 29: Gain Control

    GO-2400M-USB / GO-2400C-USB Gain Control [Analog All] can be used for gain control for both the monochrome and color camera. [Analog All] (master gain) uses the sensor's internal gain function and consists of analog gain + digital gain. Analog gain is used for lower gain, and analog gain + digital gain is used when the gain becomes high.

  • Page 30: Lut (Lookup Table)

    LUT Selector* R, G, B Select the LUT channel to control. LUT Index GO-2400M-USB: 0 to 256 Select the LUT index to configure. Indexes represent the GO-2400C-USB: 0 to 256 possible pixel values captured on the sensor, from the lowest value (Index 0) to the highest (Index 256).

  • Page 31: Gamma Function

    GO-2400M-USB / GO-2400C-USB Gamma Function The gamma function corrects the output signals from the camera beforehand (reverse correction), taking into consideration the light-emitting properties of the monitor display. As the light-emitting properties of the monitor are not linear, the entire image may be darker or the gradation in the dark areas may be less noticeable when camera outputs are displayed without processing.

  • Page 32: Shading Correction

    GO-2400M-USB / GO-2400C-USB Shading Correction The shading correction is a function that corrects non-uniformity (i.e., shading) in the amount of light generated by the lens and lighting equipment. Using this function allows correction even if top, bottom, left, and right shading is not symmetrical in relation to the center of the screen (H, V).

  • Page 33: Color Shading (Go-2400C-Usb Only)

    [Shading Mode]. Binning Function The binning function (GO-2400M-USB Only) allows you to combine the signal values of clusters of adjacent pixels on the sensor to create improved virtual pixels. Using the function results in images with lower pixel resolution and higher sensitivity.

  • Page 34: Roi (Regional Scanning Function)

    GO-2400M-USB / GO-2400C-USB ROI (Regional Scanning Function) The ROI (region of interest) function allows you to output images by specifying the areas to scan. ROI Settings Specify the area to scan by specifying width, height, and horizontal/vertical offset values under [Image Format Control].

  • Page 35: Sensor Multi Roi Function

    GO-2400M-USB / GO-2400C-USB Sensor Multi ROI Function Sensor Multi ROI is an ROI function that is configured and functions inside the sensor. You can configure up to 16 scanning regions (4 horizontal and 4 vertical). By skipping areas that are not specified as regions of interest when scanning a frame, the sensor's ROI function outputs the specified regions in a compressed state.
  • Page 36 GO-2400M-USB / GO-2400C-USB When you configure the [OffsetH], [Width], [OffsetV], and [Height] settings for an index and set [Horizontal Enable] or [Vertical Enable] to [True] for that index, the corresponding area is configured. When [False] is specified, the settings within the index are disabled.

  • Page 37: Sequencer Function

    GO-2400M-USB / GO-2400C-USB Sequencer Function The Sequencer function lets you define up to 128 preset combinations of exposure time, gain, ROI, and other settings which can be stepped through each time a trigger is received. This is particularly useful for quickly capturing multiple exposures of objects under inspection to adjust for areas or components with significantly different levels of reflectance.
  • Page 38 GO-2400M-USB / GO-2400C-USB Trigger Sequencer example User-defined Indexes (up to 128) Index1 Index2 Index3 Index4 Exposure Exposure Exposure Exposure Gain Gain Gain Gain Binning Binning Binning Binning Frame Count = 2 Frame Count = 1 Frame Count = 1 Frame Count = 2...
  • Page 39 GO-2400M-USB / GO-2400C-USB As with Trigger Sequencer, [Sequencer LUT Mode] defines whether Gamma or LUT is to be applied to the sequence. If Gamma is selected, the Gamma setting defined in the camera’s Analog Control section will be applied to all exposures in the sequence. If LUT is selected, the LUT characteristics...

  • Page 40: Delayed Readout [Acquisition Transfer Start]

    GO-2400M-USB / GO-2400C-USB Delayed Readout [Acquisition Transfer Start] Delayed readout enables images captured by a Frame Start trigger command to be stored inside the camera and read out on demand at a later time using Acquisition Transfer Start trigger. This can be especially useful when multiple cameras need to be triggered at the same time, but simultaneous readout of all images would overwhelm the available network bandwidth.

  • Page 41: Detailed Settings For Gain Auto (Automatic Gain Level Control)

    GO-2400M-USB / GO-2400C-USB Detailed Settings for Gain Auto (Automatic Gain Level Control) When [Gain Auto] is set to [Continuous], you can configure the conditions for automatic adjustment in detail. Item Description ALC Reference Specify the target level for automatic gain control. (This setting is also used for automatic exposure control.)

  • Page 42: Counter And Timer Control Function (Counter Support Only)

    GO-2400M-USB / GO-2400C-USB Counter and Timer Control Function (counter support only) The counter function counts up change points in the camera’s internal signals using the camera’s internal counter, and reads that information from the host side. This function is useful for verifying error conditions via the count value using internal camera operations.

  • Page 43: To Use The Counter Function

    GO-2400M-USB / GO-2400C-USB ■ To use the counter function Configure the settings as follows. Three counters can be configured (Counter 0 to 2). Item Setting value / selectable range Description Counter 0 to 2 Counter 0 to 2 Select the counter.

  • Page 44: Chunk Data Function

    GO-2400M-USB / GO-2400C-USB Chunk Data Function The Chunk Data function adds camera configuration information to the image data that is output from the camera. Embedding camera configuration information in the image data allows you to use the serial number of the camera as a search key and find specific image data from among large volumes of image data.

  • Page 45: Configuring Chunk Data

    GO-2400M-USB / GO-2400C-USB ■ Configuring Chunk Data Set [Chunk Mode Active] to [True]. Select the items of information you want added to image data with [Chunk Selector], and set [Chunk Enable] from [False] to [True]. Note When [Chunk Mode Active] is set to [True], [Chunk Image] is automatically set to [True].

  • Page 46: Settings List

    GO-2400M-USB / GO-2400C-USB Settings List Feature Properties : Settings that can only be configured when image acquisition on the camera is stopped. Item Setting range Default value Description Display/configure information related to a) Device Control the device. Device Vendor Name —...
  • Page 47 GO-2400M-USB / GO-2400C-USB Item Setting range Default value Description Pixel Format GO-2400M-USB: GO-2400M-USB: Set the pixel format. 8 Bit Monochrome, 8 Bit 10 Bit Monochrome, Monochrome GO-2400C-USB ： 10 Bit Monochrome Packed, 8 Bit Bayer RG 12 Bit Monochrome, 12 Bit Monochrome...
  • Page 48 Configure LUT settings. LUT Selector R, G, B Select the LUT channel to control. (GO-2400C-USB only) LUT Index GO-2400M-USB: 0 to 256 Set the LUT index table number. GO-2400C-USB: 0 to 256 LUT Value 0 to 4095 Set the LUT value.
  • Page 49 GO-2400M-USB / GO-2400C-USB Item Setting range Default value Description Counter 0 to 2 Event Off, Frame Trigger, Select the counter event signal for which Source Frame Start, to read the count value. Exposure Start, Exposure Transfer End Counter 0 to 2 Event...
  • Page 50 GO-2400M-USB / GO-2400C-USB Item Setting range Default value Description Chunk Selector Chunk Image, Image Select the information you want added to Chunk Offset X, the image data. Chunk Offset Y, * GO-2400C-USB only Chunk Width, Chunk Height, Chunk Pixel Format,...
  • Page 51 GO-2400M-USB / GO-2400C-USB Item Setting range Default value Description Pulse Generator Length 1 to 1048575 30000 Set the maximum count up value using clock value. Pulse Generator Length 0.002222 to 2330.166666 66.6667 Set the maximum count up value using (ms) This value is calculated based on the Pulse Generator Length value.
  • Page 52 Sensor Multi Roi Offset X 0 to 1680/16 steps Set the horizontal position. When binning ❖ maximum value is enabled on the GO-2400M-USB, the = 1936 - width value maximum value will change. Sensor Multi Roi Offset Y 0 to 1056/2 step Set the vertical position.
  • Page 53 GO-2400M-USB / GO-2400C-USB Item Setting range Default value Description Configure settings for other JAI functions. q) JAI Custom control Misc. Video Process Bypass On, Off Enable / disable video process bypass Mode mode. Trigger Option — OptIn Filter Selector 10 us, 100 us, 500 us, 1 ms, 10 us Select the surge protection filter.

  • Page 54: Miscellaneous

    GO-2400M-USB / GO-2400C-USB Miscellaneous Troubleshooting Check the following before requesting help. If the problem persists, contact your local JAI distributor. ■ Power supply and connections Problem Cause and solution The power / trigger LED remains lit amber and Camera initialization may not be complete due to lack of a does not turn green, even after power is network connection.

  • Page 55: Specifications

    GO-2400M-USB / GO-2400C-USB Specifications Item GO-2400M-USB GO-2400C-USB Scanning system Progressive scan, 1 tap Synchronization Internal Interface USB 3.0 Vision (Specification V1.0 RC4.02) compatible Image sensor 1/1.2-inch monochrome CMOS 1/1.2-inch Bayer color CMOS Image size (effective image) 11.3 (H) × 7.13 (V), 13.4 mm diagonal Pixel size 5.86 (H) ×...

  • Page 56: Package Contents

    GO-2400M-USB / GO-2400C-USB Item GO-2400M-USB GO-2400C-USB Gain adjustment Manual adjustment range 0 dB to +24 dB 0 dB to +24 dB Auto gain Off, Continuous Off, Continuous WB gain — R / B: –7 dB to +15 dB, 1 step = 0.1 dB...

  • Page 57: Frame Rate Reference

    GO-2400M-USB / GO-2400C-USB Frame Rate Reference (Theoretical value: decimal values are dropped) Resolution Frame rate Pixel count ROI/Binning Pixel size(μm) Image size (screen size) 8 / 10 / 12 bit 2.35 MP 1936 × 1216 Full pixel 5.86 × 5.86 1/1.2"...

  • Page 58: Dimensions

    GO-2400M-USB / GO-2400C-USB GO-2400C/2401C Sensitivity GO-2400C-USB 1000 wave length (nm) Dimensions 41.5 C Mount 12.5 23.7 4-M2 Depth3 3-M3 Depth3 Dimensional tolerance: ±0.3 Unit: mm — 58 —...

  • Page 59: User's Record

    GO-2400M-USB / GO-2400C-USB User’s Record Camera type: GO-2400M-USB / GO-2400C-USB Revision: …………….. Serial No. …………….. Firmware version. …………….. For camera revision history, please contact your local JAI distributor. Trademarks • Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the United States and other countries.

  • Page 60: Index

    GO-2400M-USB / GO-2400C-USB Index 6-pin round 9 JAI Camera Control Tool 11 JAI SDK 11 AC adapter 13 Acquisition Control 24 acquisition modes 24 LED 8 Adjusting the Black Level 20 Lens 12 Adjusting the Gain 19 Lens mount 8...

  • Page 61: Revision History

    Revision history Revision Date Changes Mar 2017 First draft...
