Texts only related to power management (AGC 24x and 22xvariants only)
Status text
BLACKOUT ENABLE
UNIT STANDBY
DELOADING BTB XX
BTB XX DIVIDING SEC.
SYNCHRONISING TB XX
SYNCHRONISING MB XX
SYNCHRONISING BTB XX
UNIT STANDBY
TB TRIP EXTERNALLY
DIVIDING SECTION
READY AUTO OPERATION
SEMI OPERATION
AUTO OPERATION
BLOCKED FOR CLOSING
BTB TRIP EXTERNALLY
BROADCASTING APPL. #
RECEIVING APPL. #
BROADCAST COMPLETED Successful broadcast of an application
RECEIVE COMPLETED
BROADCAST ABORTED
DEIF A/S
Condition
DG unit
This information is shown if a CAN failure is present in
a power management application
If redundant mains units are present, this message is
shown on the redundant unit
DG units are load sharing asymmetrically to deload
BTB XX dividing two sections in an application
BTB XX is dividing two sections in an application
TB XX is synchronising
MB XX is synchronising
BTB XX is synchronising
Mains unit
If redundant mains units are present, this message is
shown on the redundant unit
Some external equipment has tripped the breaker
BTB unit
A BTB unit is dividing two sections in an application
BTB unit in Auto and ready for breaker operation (no
active "BTB trip" alarm)
BTB unit in Semi
BTB unit in Auto, but not ready for breaker operation
(active "BTB trip" alarm)
Last open BTB in a ring bus
Some external equipment has tripped the breaker
All units
Broadcast of an application through the CAN line
AGC 200 receiving an application
Application received successfully
Broadcast terminated
Display and menu structure
Comment
An external trip is
logged in the event
log
An external trip is
logged in the event
log
Broadcasts one of
the four applica-
tions from one unit
to the other AGCs
in the power man-
agement system
