ETC ColorSource Linear Installation Manual page 2

ETC Installation Guide
ColorSource Linear v1.5
Environment
The ColorSource Linear operates in ambient temperatures of 0°C–40°C and
comes with a variable-speed fan.
Note: The ColorSource Linear is for indoor use only.
Note: • Maximum recommended ambient operating
Electrical
WARNING:
• Operates between 100V and 240VAC at a frequency of 50/60Hz.
• Maximum power consumption:
- Linear 1: 120W
- Linear 2: 240W
- Linear 4: 480W
• Maximum number of fixtures to be linked via power thru connector
when used with an R20 relay module or Unison Echo
- Linear 1: 9 luminaires (10 luminaires total per circuit)
- Linear 2: 7 luminaires (8 luminaires total per circuit)
- Linear 4: 3 luminaires (4 luminaires total per circuit)
Consult breaker trip curves when used with other equipment.
Requires power from a non-dimmable source.
ColorSource Linear v1.5
temperature: Ta = 40°C (104°F)
• Maximum anticipated external surface temperature
at 40°C ambient: Tmax = 80°C (176°F)
• External temperatures after 5 minutes of full-
brightness operation at 25°C (77°F) ambient:
36°C (97°F)
• External temperature (steady state achieved) at
25°C (77°F): 48°C (118°F)
Disconnect the fixture from power and DMX and allow
it to cool before performing any cleaning and
maintenance.
Page 2 of 16
®
