2.1.1 ACTIVATE KEYBOARD WEDGE & SELECT KEYBOARD TYPE
When Keyboard Wedge interface is activated, it will have to select a keyboard type to
complete this setting.
1) Read this barcode above to activate Keyboard Wedge and select a keyboard type.
2) Read the "Decimal
number of desired keyboard type.
3) Read the "Validate" barcode on the same page to complete this setting.
Keyboard Type
By default, the keyboard type is set to PCAT (US). The following keyboard types are supported –
No. Keyboard Type
1 PCAT (US)
2 PCAT (French)
3 PCAT (German)
4 PCAT (Italian)
5 PCAT (Swedish)
6 PCAT (Norwegian)
7 PCAT (UK)
8 PCAT (Belgium)
9 PCAT (Spanish)
10 PCAT (Portuguese)
11 PS55 A01-1
12 PS55 A01-2 (Japanese)
13 PS55 A01-3
14 PS55 001-1
15 PS55 001-81
16 PS55 001-2
17 PS55 001-82
Value" barcode on page 183. Refer to the table below for the
Chapter 2
Activate Keyboard
Wedge & Select
Keyboard Type...
No. Keyboard Type
18 PS55 001-3
19 PS55 001-8A
20 PS55 002-1, 003-1
21 PS55 002-81, 003-81
22 PS55 002-2, 003-2
23 PS55 002-82, 003-82
24 PS55 002-3, 003-3
25 PS55 002-8A, 003-8A
26 IBM 3477 Type 4 (Japanese)
27 PS2-30
28 IBM 34XX/319X, Memorex Telex 122 Keys
29 User-defined table
30 PCAT (Turkish)
31 PCAT (Hungarian)
32 PCAT (Swiss German)
33 PCAT (Danish)
Update
Selecting Output Interface
37
