2.3 DIRECT USB HID

For USB HID, connect the scanner to the USB port of PC. Run any text editor on the
computer, and the scanned data will be transmitted to the computer.
HID Settings
Keyboard Type
Digits Layout
Capital Lock Type
Capital Lock State
Alphabets Transmission
Digits Transmission
Kanji Transmission
Inter-Character Delay
Inter-Function Delay
2.3.1 ACTIVATE USB HID & SELECT KEYBOARD TYPE
When USB HID interface is activated, it will have to select a keyboard type to complete
this setting.
1) Read the barcode above to activate USB HID and select a keyboard type.
2) Read the "Decimal
number of desired keyboard type.
3) Read the "Validate" barcode on the same page to complete this setting.
USB HID
By default, the keyboard type is set to PCAT (US). The following keyboard types are supported —
No. Keyboard Type
64 PCAT (US)
65 PCAT (French)
66 PCAT (German)
67 PCAT (Italy)
68 PCAT (Swedish)
69 PCAT (Norwegian)
70 PCAT (UK)
Value" barcode on page 183. Refer to the table below for the
Chapter 2
Defaults
PCAT (US)
Normal
Normal
Off
Case-sensitive
Alphanumeric keypad
Disable
0 (ms)
0 (ms)
Activate
Direct USB HID &
Select Keyboard
Type...
No. Keyboard Type
72 PCAT (Spanish)
73 PCAT (Portuguese)
74 PS55 A01-2 (Japanese)
75 User-defined table
76 PCAT (Turkish)
77 PCAT (Hungarian)
78 PCAT (Swiss German)
Update
Selecting Output Interface
