Universal Power Adaptor
UMX-OPT-TX150R transmitter is equipped with a universal +5V DC power adaptor, which
accepts AC voltages from 100 to 240 Volts with 50 or 60 Hz line frequency.
Locking DC Connector
Special plug of wall adaptor ensures safe power supply. This type of connector prevents
acccidental disconnections.
Rack Mounting Options
Several mounting methods ensure universal usage. Units can be placed into standard
racks or under flat surfaces.
1.4. Compatible Devices
Cross compatibility between all the devices in the product series is ensured thanks to
Lightware's attentive design. The transmitter can be paired with any receiver without
restriction. With Lightware's Hybrid Modular Matrix concept, it is even possible to connect
the UMX-OPT-TX150R directly to the matrix router using an MX-HDMI-OPT or MX-DVI-OPT
series input board. You can see the list of compatible devices below:
Chapter 1. Introduction
Product name
DVIDL-OPT-RX100
DVI-OPT-RX110
DVI-OPT-RX220-Pro
HDMI-3D-OPT-RX150RA
HDMI-OPT-RX100
HDMI-OPT-RX100R
HDMI-OPT-RX200R
MX-DVI-OPT-IB
MX-HDMI-OPT-IB
UMX-OPT-TX150R
Product group
DVIDL-OPT series
DVI-OPT-110 series
DVI-OPT-220 series
HDMI-3D-OPT series
HDMI-OPT series
HDMI-OPT series
HDMI-OPT series
MX Boards
MX Boards
