3.9

Anti-tipper

(1) To activate
• push the anti-tipper (A) down using the tread
element (B),
• turn it 180°
• and let go so the positioning slot snaps into
the arresting bolt (C) inside the pipe.
To deactivate
• push the anti-tipper on the pipe (A) slightly
further down,
• turn it 180° and let go so it snaps into the
positioning slot.
ATTENTION
Please read the respective chapters of the SAFETY
INTRUCTIONS.
ATTENTION
Make sure that the extension is always firmly
snapped into its final position because a loose an-
ti-tipper cannot fulfil its function properly and may
cause injuries of the assistant's ankle area.
(1)
(A)
(2)
(B)
(A)

3.10 HEAD RESTS

There are two versions of the head rest - with a
square-type tube (2) or a special section tube (3).
Both kinds can be adjusted to the user in the same
way:
(2+3) Height adjustment:
• open the eccentric clamps (A)/star screw (A),
• adjust the desired height,
• tighten screws/clamps (A) firmly.
Adjustment of distance:
• open clamp lever (B),
• adjust the desired distance,
• tighten clamp lever firmly.
ATTENTION
The head rest is only suitable for transportation in a
passenger car to a certain degree. The reservations
and requirements described in our "crash test"
brochure concerning the use of the head rest in a
passenger car are absolutely binding!
ATTENTION
We recommend using a head support firmly
installed in the vehicle (not part of the wheelchair)
for transportation in a passenger car.
(2)
(B)
(3)
(B)
(A)
(B)
(A)
