Special Hand Rims; Knob Hand Rims; Hand Rim Covers / Maxgrepp Hand Rims; Back - SORG MIO MOVE User Manual

3.3

SPECIAL HAND RIMS

3.3.1 Knob hand rims

ATTENTION INJURY RISK!
Regard that the knob hand rims turn when you are
being pushed!
ATTENTION
Braking with pressure on the hand rims is not
possible. This applies especially when driving
downhill. Let an experienced and strong carer assist
you.

3.3.2 Hand rim covers / Maxgrepp hand rims

ATTENTION
All hand rim covers and the Maxgrepp hand rim are
made out of several black synthetic materials and
can heat to over 42° in the sun.
ATTENTION
Under unfavorable circumstances the black coating
can stretch from the heat and can detach from the
hand rim.
3.4

BACK

ATTENTION
BEFORE TILTING ALWAYS ACTIVATE THE ANTI
TIPPER.
ATTENTION
THE BACK AND THE BACK-SEAT UNIT CAN ONLY BE
ADJUSTED STANDING STILL WITH LOCKED BRAKES
AND ON A FLAT, HARD SURFACE TO MORE THAN
90°.
ATTENTION
NEVER USE THE TILT MECHANISM WHILE DRIVING.
ATTENTION
With a tilted wheelchair and/or a back angle >90°
a suitable support for the head is necessary (head
rest or a back extension which can be lowered).
ATTENTION
Do not hang things (such as bags etc.) on the push
handle; especially not in a tilted position and/or a
back angle >90°.

3.4.1 Tilting

To release the tilt function:
• (1-3) pull the lever (A) up and
• squeeze it until the desired position is
reached.
• Then let it go and let the tilting mechanism
snap into place.
(1)
(A)
(2)
(3)
User Manual
(A)
15
