SITRANS Probe LR
Operating Instructions 01/2011
SITRANS

Advertisement

Table of Contents
loading

Related Manuals for Siemens Sitrans Probe LR

Summary of Contents for Siemens Sitrans Probe LR

  • Page 1 Radar Transmitters SITRANS Probe LR Operating Instructions 01/2011 SITRANS...
  • Page 2 The user is responsible for all changes and repairs made to the device by the user or the user’s agent. • All new components are to be provided by Siemens Milltronics Process Instruments. • Restrict repair to faulty components only.

  • Page 3: Table Of Contents

    Support ............................2 Abbreviations and Identifications ...................2 SITRANS Probe LR ......................4 Applications ..........................4 SITRANS Probe LR System Implementation ................5 Programming ..........................5 SITRANS Probe LR Approvals and Certificates ..............5 Specifications ........................7 SITRANS Probe LR ..........................7 Power............................. 7 Performance..........................7 Interface ............................8 Programmer (infrared keypad) ....................
  • Page 4 Quick Setup for local operation (outline) ..................24 Setup Instructions ........................24 Additional Settings ..........................29 Application Examples ....................30 Example 1: Liquid resin in storage vessel, level measurement ........30 Example 2: Horizontal vessel with volume measurement ..........32 Parameter Reference ....................35 Helpful Hints ..........................35 To access a parameter and change a value (primary index): ........
  • Page 5 EU Equivalency ........................101 Loop Voltage versus Loop Resistance ................102 IS Safety Barrier Selection ....................102 How to select a passive barrier for SITRANS Probe LR ..........102 PLC Input Modules......................... 103 Passive Shunt Diode Barriers .................... 103 Active barriers (repeating barriers)................... 103...
  • Page 6 Instructions specific to hazardous area installations ..............104 (Reference European ATEX Directive 94/9/EC, ..............104 Annex II, 1/0/6) .........................104 Product Nameplate ..........................105 Intrinsically safe connection drawing (FM) ................106 Intrinsically safe connection drawing (CSA) ................107 Non-incendive connection drawing (FM) ...................108 Appendix H: Firmware Revision History ..............109 Glossary ..........................111 Index ..........................115...

  • Page 7: Safety Notes

    • This product is intended for use in industrial areas. Operation of this equipment in a residential area may cause interference to several frequency based communications. This manual will help you set up your SITRANS Probe LR for optimum performance. We always welcome suggestions and comments about manual content, design, and accessibility.

  • Page 8: Application Examples

    Application Examples The application examples used in this manual illustrate typical installations using SITRANS Probe LR. Because there is often a range of ways to approach an application, other configurations may also apply. In all examples, substitute your own application details. If the examples do not apply to your application, check the applicable parameter reference for the available options.
  • Page 9 20 mA above which no PV is Upper Sensor Limit anticipated 100% is most commonly set to 20 mA, and 0% to 4 mA: however, the settings can be reversed. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 3...

  • Page 10: Sitrans Probe Lr

    Notes: • Please refer to product label for approval information. • SITRANS Probe LR is to be used only in the manner outlined in this manual, otherwise protection provided by the equipment may be impaired. SITRANS Probe LR is designed to measure liquid levels in a variety of applications: •...

  • Page 11: Sitrans Probe Lr System Implementation

    HART communicator Programming SITRANS Probe LR carries out its level measurement function according to the set of built-in parameters. You can make parameter changes via the handheld programmer, via a PC using SIMATIC PDM, or via a HART Handheld Communicator.
  • Page 12 Notes Page 6 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 13: Specifications

    Specifications Notes: • Siemens makes every attempt to ensure the accuracy of these specifications but reserves the right to change them at any time. Enclosure • Please check the ambient and operating temperatures under on page 9, Approvals (verify against device nameplate) Approvals on page 10;...

  • Page 14: Interface

    (representing level) Programmer (infrared keypad) Siemens Milltronics Infrared IS (Intrinsically Safe) Handheld Programmer for hazardous and all other locations (battery is non-replaceable) • approval: ATEX II 1 G, EEx ia IIC T4, certificate SIRA 01ATEX2147 FM/CSA Class 1, Div.

  • Page 15: Mechanical

    Type 4X / NEMA 4X, Type 6 / NEMA 6, IP67, IP68 enclosure (see note below) • installation category: • pollution degree: Unit with 100 mm (4") rod and adaptors 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 9...

  • Page 16: Process

    • Marine Lloyd’s Register of Shipping ABS Type Approval EN 61000-4-3 (CE EMC) testing was conducted on the SITRANS Probe LR while Note: mounted in a metallic vessel. See 'Intrinsically safe connection drawing (FM)' on page 106 for drawing number 23651611, or 'Intrinsically safe connection drawing (CSA)' on page 107 for drawing number 23651621.

  • Page 17: Installation

    • Installation shall only be performed by qualified personnel and in accordance with local governing regulations. • SITRANS Probe LR ‘is to be used only in the manner outlined in this manual, otherwise protection provided by the device may be impaired.

  • Page 18: Mounting Location

    (The concavity of the top can focus echoes into the centre, giving false readings.) Under certain circumstances, it may be acceptable to mount SITRANS Probe LR Note: at the centre of a flat-topped tank: please discuss this with your Siemens Milltronics representative. Coni preferred...
  • Page 19 • For more detail on false False-Echo echoes, see Suppression on page 94. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 13...

  • Page 20: Location On A Nozzle, Or On A Manhole Cover

    Before inserting SITRANS Probe LR into its mounting connection, check to ensure the threads are matching, to avoid damaging them. Simply screw SITRANS Probe LR into the process connection, and hand tighten. For pressure applications, it will be necessary to use PTFE tape (or other appropriate thread sealing compound) and tighten the process connection beyond hand tight.

  • Page 21: Sitrans Probe Lr: Dimensions

    100 mm (4") [optional: 250 mm (10")] std. 552 mm (21.7") min. std. 139 mm (5.47") polypropylene option 702 mm (27.6") max. rod antenna [optional 289 mm (11.38")] 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 15...

  • Page 22: Wiring

    (1 of 2) strain relief locking collar (or NPT cable entry) Safety Extra Low Voltage If cable is routed through conduit, use only approved suitable-size hubs for waterproof applications. Page 16 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...
  • Page 23 Close the lid and tighten screws: please do not overtighten screws. (Recommended torque is 1.1 to 1.7 N-m (10 to 15 in-lb) of torque.) If cable is routed through conduit, use only approved suitable-size hubs for waterproof applications. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 17...

  • Page 24: Operating Sitrans Probe Lr

    SITRANS Probe LR has two modes of operation: RUN and PROGRAM. RUN Mode SITRANS Probe LR automatically starts in RUN mode when power is applied, and detects the material level. The primary reading displays the material level (in meters) referenced from Empty (process empty level).

  • Page 25: Program Mode

    Activate PROGRAM mode at any time, to change parameter values and set operating conditions. • For local programming, use the Siemens handheld programmer. • For programming from a distance, use either a PC running SIMATIC PDM, or a HART handheld communicator.

  • Page 26: Low Temperature Effects On Run/Program Modes

    RUN mode will operate normally, with the following exceptions: • handheld programmer operation is disabled • the LCD displays only limited information: the bar graph and the reliable/ unreliable echo indicator PROGRAM mode: • handheld programmer operation is disabled Page 20 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 27: Security

    For detailed instructions on using the handheld programmer, see the next page. Note: For direct access to SITRANS Probe LR, point the handheld programmer at the display from a maximum distance of 600 mm (2 ft), and press the keys.

  • Page 28: Activating Sitrans Probe Lr

    Note: SITRANS Probe LR to prevent inadvertent operation. Power up the instrument. SITRANS Probe LR starts in RUN mode, and detects the material level. It displays the material level (in meters) referenced from Empty (process empty level). This is the default start-up mode.

  • Page 29: Changing A Parameter Value

    Press DISPLAY to open parameter fields. Key in 999. Press CLEAR then ENTER , to Clear All and initiate reset. The LCD displays C.ALL. Reset complete. (Reset takes several seconds to complete.) 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 23...

  • Page 30: Using Units Or Percent (%)

    • The default parameter values are indicated by an asterisk (*) in the tables. Using the handheld programmer, set each parameter value to suit your application. (For detailed instructions on accessing a parameter and changing the value, see page 22.) Page 24 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...
  • Page 31 (20 mA) (4 mA) (20 mA) The parameter title appears in the language selected, for parameters P000 to P010. SITRANS Probe LR: Dimensions For the reference point, see on page 15. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 25...
  • Page 32 Value Near Blanking Default blanking distance is 0.3 m (1 ft). For more details, see on page 93. For the reference point for the standard configuration, see page 15. Page 26 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...
  • Page 33 SITRANS Probe LR: Dimensions For the reference point, see on page 15. 0.3 m (1 ft), plus the shield length (if any). 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 27...
  • Page 34 "base noise" caused by internal antenna reflections, nozzle echoes, or other vessel false echoes P838 allows you to set a distance, within which SITRANS Probe LR will learn a new echo profile. Set P838 in combination with P837: see the Setup Instructions below.

  • Page 35: Additional Settings

    TVT curve adjustments - Auto False-Echo Suppression (P831 to P839) • Software diagnostic tests (P900 to P901) • Adjust measurements (P911 to P924) Parameter Reference For a full list of available parameters, see , starting on page 35. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 29...

  • Page 36: Application Examples

    4.5 m from the vessel bottom. The maximum rate of (P007) filling or emptying is about 0.2 m/min. In the event of a loss of echo, SITRANS Probe LR is to go into Failsafe Hi after 2 minutes. 0% Level Empty Page 30 SITRANS Probe LR –...
  • Page 37 Distance to product from reference point. For more details on setting P837 and P838, see page 64. For an explanation, Auto False-Echo Suppression on page 94. Return to RUN: press PROGRAM to start normal operation. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 31...

  • Page 38: Example 2: Horizontal Vessel With Volume Measurement

    0.2 m/min. Selecting tank shape 7 at P050, and entering values for A and L, will give a volume reading instead of level. In the event of a loss of echo, SITRANS Probe LR is to go into Failsafe Hi after 2 minutes. reference point 3.5 m...
  • Page 39 Distance to product from reference point. For more details on setting P837 and P838, see page 64. For an explanation, Auto False-Echo Suppression on page 94. Return to RUN: press PROGRAM to start normal operation. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 33...
  • Page 40 Notes Page 34 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 41: Parameter Reference

    SITRANS Probe LR is configured through its parameters, and the application determines the parameter values which are entered into the instrument. Please check your value entries carefully before operating SITRANS Probe LR, to ensure optimum performance. Helpful Hints •...

  • Page 42: To Access A Secondary Index And Change A Value

    4. Key in the new index value and press ENTER 5. Press DISPLAY twice, then use the ARROW keys or key in the parameter number to select a different parameter. This focusses control on the secondary index. Page 36 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...
  • Page 43 • This lock only applies to the handheld programmer: it does not lock access through communications. • A remote master can change configuration if P799 is set to allow this. Secures SITRANS Probe LR from parameter changes via the handheld programmer. Unlocked Value (P069) Unlocked: programming permitted...

  • Page 44: Quick Start (P001 To P010)

    Span Distance Span 100% Space P006 P007 Level Empty Empty Empty 100% 100% 20 mA 4 mA 20 mA SITRANS Probe LR: Dimensions For the reference point, see on page 15. Page 38 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 45: Measurement Response

    Failsafe default (P071) is triggered. P070 takes precedence over P003. P004 Antenna Type Specifies the antenna type attached. rod antenna Values Near Blanking on page 93 for more details. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 39...

  • Page 46: P005 Units

    • Default setting is maximum range. Level • P006 and P007 are interlinked: see note Empty attached to P007. SITRANS Probe LR: Dimensions For the reference point, see on page 15. Page 40 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 47: P007 Span

    If a language is selected, parameter titles for the parameters P000 to P010 are displayed. (See the table on page 25 for the titles displayed.) Near Blanking on page 93 for details. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 41...

  • Page 48: Volume (P050 To P055)

    : the displayed volume reading will be a percentage of Maximum Volume. P050 Vessel Shape Defines the vessel shape (see chart on next page) and allows SITRANS Probe LR to calculate volume instead of level. The default setting for P050 is 0 (volume calculation not required).
  • Page 49 P051, P052 spherical bottom P051, P052 angled bottom P051, P052 flat end cylinder P051 parabolic end cylinder P051, P052, P053 P051 sphere universal linear P051, P054, P055 level/volume breakpoints 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 43...

  • Page 50: P052 Vessel Dimension A

    0.0000 to 99999 in units (P005) Values Default P050 Vessel Shape Related Parameters Enter the vessel length L (excluding both end sections) if P050 = 7. Use the units selected in P005. Page 44 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...
  • Page 51 Repeat steps 6 and 7 until level values have been entered for all the required breakpoints. Example: Breakpoints Level value Level Volume Breakpoint breakpoint breakpoint 20 m Number (P054) (P055) 3000 8000 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 45...
  • Page 52 P055 Volume Breakpoints Each segment defined by the level breakpoints (P054) requires a corresponding volume for SITRANS Probe LR to make the level-to-volume calculations. P055 Primary Index Breakpoint number Secondary Index Range 0.0000 to 99999 in units Values Default 0.0000...

  • Page 53: Lock (P069)

    • After a new value has been stored at P069, that value will be recalled after a master reset (P999). • Consult your Siemens representative, if you have forgotten the unlocked value. Failsafe (P070 to P073) Factory settings are indicated by an asterisk (*) in the parameter tables, unless Note: explicitly described.

  • Page 54: Ma Output (P201 To P215)

    P001. If a HART master is connected, only the master can change the value. manual level space Values distance volume (only available if a tank shape has been selected at P050) Page 48 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...
  • Page 55 (P007) as referenced from Empty (P006). Key in the volume in Maximum Volume (P051) units or as a Volume percent of Maximum Volume. Ensure the % symbol is displayed before entering a % value. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 49...
  • Page 56 P201: mA Output Function) P201: mA Output Function Related Parameters Enter the reading that is to correspond to a 20 mA output. Use percent or units, depending on the setting for P051 Page 50 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...
  • Page 57 Prevents the mA output from rising above this maximum level for a measurement value. This does not restrict the Failsafe or manual settings. Range 3.8 to 20.5 (mA) Values Default 20.5 (mA) 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 51...

  • Page 58: Installation Records (P341 To P346)

    P214 4 mA Output Trim This parameter is for use only by Siemens service personnel. Note: Calibrates the 4 mA output. P215 20 mA Output Trim This parameter is for use only by Siemens service personnel. Note: Calibrates the 20 mA output.

  • Page 59: Range Calibration (P652 To P655)

    Factory settings are indicated by an asterisk (*) in the parameter tables, unless Note: explicitly described. P652 Offset Correction A fixed offset value that is added to the reading as a correction to the measurement. Range –99999 to 99999 Values Default 0.000 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 53...
  • Page 60 100 mm (4”) 0.955 150 mm (6”) 0.980 200 mm (8”) 0.990 Contact your Siemens representative for other sizes and propagation factor numbers. The propagation factor is constant for a given pipe diameter, or can be determined by SITRANS Probe LR distance...

  • Page 61: Rate (P700 And P701)

    These parameters determine how material level changes are reported. P700 Maximum Fill Rate Allows you to further adjust the SITRANS Probe LR response to increases in the actual material level (or an advance to a higher Failsafe Material Level, P071). P700 is automatically updated whenever Measurement Response (P003) is altered.

  • Page 62: Measurement Verification (P709 To P713)

    P701 Maximum Empty Rate Adjusts the SITRANS Probe LR response to decreases in the actual material level (or an advance to a lower Failsafe Material Level, P071). P701 is automatically updated whenever Measurement Response (P003) is altered. 0.0000 to 99999...
  • Page 63 The window then returns to its normal width. When Echo Lock is Off, SITRANS Probe LR responds immediately to a new measurement, as restricted by the Maximum Fill / Empty Rate (P700 / P701). However, measurement reliability is affected.
  • Page 64 When a new measurement falls within the window, the window is re-centered and the new reading calculated. Otherwise, the new measurement is verified by Echo Lock (P711) before the reading is updated. Units are those set in P005. Page 58 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 65: Communications (P799)

    Notes: • P799 controls the access if you are using a HART master. • P000 controls the lock access if you are using the Siemens handheld programmer. Echo Processing (P800 to P807) Factory settings are indicated by an asterisk (*) in the parameter tables, unless Note: explicitly described.
  • Page 66 Enter the value as a percentage of P006. • For vessels with conical or parabolic bottoms, increase the value for P801 to ensure that an empty vessel reads Empty. Near Blanking For more details, see on page 93. Page 60 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...
  • Page 67 Displays the absolute strength (in dB above 1 μV rms) of the echo selected as the measurement echo. Range –20 to 99 Values (view only) Press the measurement key to get a new reading that will update echo strength. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 61...

  • Page 68: Algorithm (P820)

    Selects the algorithm to be applied to the echo profile to extract the true echo. argest echo Reserved Values best of Largest or irst echo First echo For more clarification on the different options, please contact your local representative. Page 62 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 69: Tvt (Time Varying Threshold) Adjustment Parameters (P831 To P839)

    Factory settings are indicated by an asterisk (*) in the parameter tables, unless Note: explicitly described. First SITRANS Probe LR learns the echo profile. Then the learned profile, or part of the learned profile, is used to screen out false echoes. The following parameters are for authorized Siemens Service personnel or technicians familiar with Siemens echo processing techniques.
  • Page 70 Use "learned" TVT "Learn" If SITRANS Probe LR displays a full level, or if the reading fluctuates between a false high level and a correct level, you can use the TVT shaper parameters P837 and P838 together to prevent false-echo detection. They elevate the TVT in this region and de-sensitize the receiver from any ‘base noise"...
  • Page 71 Display before Auto False-Echo Suppression (or when P837 = 0) default TVT P839 hover level Distance (meters) Example After Auto False-Echo Suppression TVT curve (learned) material level false echo Distance (meters) 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 65...

  • Page 72: Test (P900 To P924)

    P839 TVT Hover Level Defines (in percent) how high the TVT curve is placed above the profile, relative to the largest echo. When SITRANS Probe LR is located in the center of the vessel, lower this parameter to prevent multiple echo detections.

  • Page 73: Measurement

    (read only) P921 Material Measurement Displays the distance between Empty/process empty level (P006) and the monitored surface, in Units (P005) or percent of Span (P007). Range –99999 to 99999 Values (view only) 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 67...
  • Page 74 Clear All and initiate reset. 3. Reset complete. (Note: Reset takes several seconds to complete.) SITRANS Probe LR: Dimensions For the reference point for the standard model, see on page 15. Page 68 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 75: Appendix A: Alphabetical Parameter List

    Echo Lock Window Echo Strength Empty / process empty level Failsafe Level Failsafe Material Level Failsafe Timer Internal Temperature Language Lock mA Output Function mA Output Value (HART / mA only 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 69...
  • Page 76 Propagation Factor Range Extension Reading Measurement Serial Number RUN Time Software Revision Number Space Measurement Span / process full level TVT Hover Level TVT Shaper TVT Shaper Adjust Units Unlocked Value Page 70 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...
  • Page 77 Parameter Name Parameter Number Page Number Vessel Dimension A Vessel Dimension L Vessel Shape Volume Breakpoints Volume Measurement 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 71...

  • Page 78: Appendix B: Programming Chart

    P073 Failsafe level P201 mA Output Function P210 4 mA Setpoint (low output) P211 20 mA Setpoint (high output) P212 Minimum mA limit P213 Maximum mA limit P214 4 mA Output Trim Page 72 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 79: Auto False-Echo Suppression

    P807 Noise P820 Echo Algorithm P831 Manual TVT Shaper P832 Manual TVT Shaper Adjust P837 Auto False-Echo Suppression P838 Auto False-Echo Suppression Distance P839 TVT Hover Level P900 Software Revision Number 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 73...
  • Page 80 Parameter Number and Name Value P901 Memory Test P911 mA Output Value (HART/mA only) P920 Reading Measurement P921 Material Measurement P922 Space Measurement P923 Distance Measurement P924 Volume Measurement P999 Master Reset Page 74 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 81: Appendix C: Hart

    Communication Foundation. Please contact your local Siemens representative concerning the availability of the HART EDD for SITRANS Probe LR. Older versions of the library will have to be updated in order to use all the features in the SITRANS Probe LR.

  • Page 82: Hart Communicator 275/375

    6. Manufacturer data 1. Serial No 2. Revision HART information 1. Manufacturer 2. Model 3. HART Dev ID 4. Universal rev 5. Fld dev rev 6. Software rev 7. Hardware rev Page 76 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 83: Language 010

    1. mA Function cylinder parabol end 2. FS Timer sphere 3. FS default measure universal linear 4. FS Advance 5. FS level val Bk LevVol Gr Bk LevVol 1_32 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 77...

  • Page 84: Lock

    6. Low Setpoint 7. High Setpoint Local Display 1. Write protect 2. Lock 3. Write Protect 4. unlock value HART Output 1. Poll addr 2. Num req preams 3. Num resp preams Page 78 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 85: Simatic Process Device Manager (Pdm)

    SIMATIC Process Device Manager (PDM) This software package is designed to permit easy configuration, monitoring, and troubleshooting of HART devices. The HART EDD for SITRANS Probe LR was written with SIMATIC PDM in mind and has been extensively tested with this software.

  • Page 86: Hart Version

    Maintenance Alert Activation Total Calibration Interval Units Maintenance Status Acknowledge Status Acknowledge HART Version SITRANS Probe LR conforms to HART rev. 5. Burst mode SITRANS Probe LR does not support burst mode. Page 80 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 87: Appendix D: Troubleshooting

    FAQs for SITRANS Probe LR, or contact your local Siemens representative. Specifically: If you try to set a SITRANS Probe LR parameter via remote communications, but the parameter remains unchanged: • Some parameters can only be changed when the device is not scanning. Try putting the device in PROGRAM mode using the operating mode function.

  • Page 88: General Fault Codes

    Service interval as defined in Maintenance Perform service. Required Limit has expired. Service interval as defined in Maintenance Perform service. Demanded Limit has expired. S:11 Internal temperature sensor failure. Repair required: contact your local Siemens representative. Page 82 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...
  • Page 89 S:36 * Unable to start microwave module. Reset power. If error persists, contact your local Siemens representative. S:37 * Measurement hardware problem. Reset power. If error persists, contact your local Siemens representative. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 83...
  • Page 90 S:53 * Configuration lost: one or more parameter Restore user parameters using settings have been lost. This may occur after SIMATIC PDM. a firmware upgrade causes user parameters to be reset. Page 84 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 91: Fault Codes (Firmware Revision 1.05 Or Earlier)

    Do not use the device for measurement, but return it to the factory as soon as possible. 26 * A mechanical failure in the device, such as a None broken cable. Standard device error category None 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 85...
  • Page 92 Internal device failure caused by a memory The fault should never appear. If it error. does, the device should reset itself and there is no action to be taken, It should be reported to the factory. Page 86 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...
  • Page 93 EEPROM can become corrupted due to operating the device outside its operating range (power and temperature), or other damage. EEPROM can become corrupted due to operating the device outside its operating range (power and temperature), or other damage. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 87...

  • Page 94: Operation Troubleshooting

    LOE and status • temperature too high well symbol shows • physical damage • relocate • excessive foam • use a defoamer • multiple echoes • set P820 to 12 (First echo) Page 88 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...
  • Page 95 • relocate instrument to side Reading erratic pipe • increase confidence threshold P804 • re-locate SITRANS Probe LR material filling • increase measurement Reading P003 setting response if possible response slow 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 89...
  • Page 96 • nozzle too narrow for length • shielded antenna required: discuss with your Siemens representative. • internal seam in nozzle • inspect and remove seam • use P837/P838 • longer shield required Page 90 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 97: Maintenance

    Maintenance SITRANS Probe LR requires no maintenance or cleaning under normal operating conditions. Under severe operating conditions, the antenna may require periodic cleaning. If cleaning becomes necessary: • Note the antenna material and the process medium, and select a cleaning solution that will not react adversely with either.

  • Page 98: Appendix E: Technical Reference

    This distance is used as a basis for the display of material level and mA output. Transceiver The SITRANS Probe LR transceiver operates under one of three sets of pre-set conditions which affect the speed of the measurement response (P003). Echo...

  • Page 99: Typical Receiver Signal

    (P801) as % P006 Near Blanking Near Blanking programs SITRANS Probe LR to ignore the zone in front of the antenna. The default blanking distance is 0.3 m (1 ft) plus any shield length, from the reference point P800 allows you to increase the near blanking value from its factory setting. But Auto False-Echo Suppression (P837) is generally recommended in preference to extending the blanking distance from factory values.

  • Page 100: Range Extension

    SITRANS Probe LR will ignore false echoes in your application. P838 allows you to set a distance, and P837 then instructs SITRANS Probe LR to "learn" where the obstructions/false echoes are within that distance. If possible, rotate the instrument before using Auto False-Echo Suppression, to lower the amplitude of false echoes.
  • Page 101 Display before Auto False-Echo Suppression (or when P837 = 0) Default TVT P839 Hover Level Distance (meters) Example After Auto False-Echo Suppression TVT curve (Learned) material level false echo Distance (meters) 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 95...

  • Page 102: Run/Program

    (20 mA) (20 mA) When SITRANS Probe LR is put into PROGRAM mode it stops responding to the process. It stores the most recent measurement, and holds the associated readings and mA signal output. The instrument reverts to the parameter last addressed during the previous program session.

  • Page 103: Failsafe

    82), the instrument will go into Failsafe mode without delay. Chemical compatibility The plastic materials used in the construction of SITRANS Probe LR (polypropylene, , and PEI ) are resistant to attack from most chemicals. For exposure to specific environments, check with chemical compatibility charts before installing and operating SITRANS Probe LR in your application.

  • Page 104: Appendix F: Special Applications

    Appendix F: Special Applications This more complex SITRANS Probe LR application example can be used as a setup reference. The parameter value tables relate the values to the functions. Application Example: Stilling-well This is typically recommended for products with an ε...
  • Page 105 P655 Value (Typical)* 50 mm (2”) 0.827 80 mm (3”) 0.915 100 mm (4”) 0.955 150 mm (6”) 0.980 200 mm (8”) 0.990 * These values are provided as a guideline only. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 99...

  • Page 106: Appendix G: Hazardous Area Installations

    Instructions specific to hazardous area installations Wiring Details Intrinsically Safe Model (reference drawing 23651611) (reference drawing 23651621) Under the entity evaluation concept, SITRANS Probe LR has the following characteristics: = 30 V DC (max.) (input voltage) U = 120 mA DC (max.) (input current) I = 3.6 nF...

  • Page 107: Fm/Csa

    • The safe area is unspecified except that it must not be supplied from nor contain, under normal or abnormal conditions, a source of potential with respect to earth in excess of 250 V rms or 250 V DC. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 101...

  • Page 108: Loop Voltage Versus Loop Resistance

    How to select a passive barrier for SITRANS Probe LR Make sure that the barrier safety description is suitable for the SITRANS Probe LR Intrinsically Safe (IS) input parameters. Determine the maximum end-to-end resistance of the barrier (Re-e) from the data sheet.

  • Page 109: Plc Input Modules

    Notes: • The following list is not complete: there are many safety barriers on the market, which will work with the SITRANS Probe LR. • The barriers listed below have all been tested and are functionally compatible with the SITRANS Probe LR.

  • Page 110: Instructions Specific To Hazardous Area Installations

    12. Equipment Marking The equipment marking contains at least the information on the product nameplate, shown on page 105. Page 104 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 111: Product Nameplate

    Product Nameplate 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 105...

  • Page 112: Intrinsically Safe Connection Drawing (Fm)

    Intrinsically safe connection drawing (FM) Drawing number 23651611 Page 106 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 113: Intrinsically Safe Connection Drawing (Csa)

    Intrinsically safe connection drawing (CSA) Drawing number 23651621 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 107...

  • Page 114: Non-Incendive Connection Drawing (Fm)

    05 / MAR / 2004 R. CLYSDALE SITRANS LR 200 / PROBE LR T. LITTLE CLASS I, Div. 2 S. NGUYEN CONNECTION DRAWING PETERBOROUGH FOR INTERNAL USE ONLY 23650537 2365053701 1 : 1 Page 108 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 115: Appendix H: Firmware Revision History

    Fault system upgraded to use S# codes to match PROFIBUS products. • Increased number of level/volume breakpoints to 32. • Improved linearity over ambient temperature. NOTE: Software revision 3.02 is not backwards compatible due to hardware compatibility. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 109...
  • Page 116 Notes: Page 110 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 117: Glossary

    Its value is expressed as the ratio of a quantity of electricity to a potential difference, and the unit is a Farad. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 111...
  • Page 118 Generally, false echoes are created by vessel obstructions. 1. Many conductive liquids/electrolytes exhibit dielectric properties; the relative dielectric constant of water is 80. Page 112 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...
  • Page 119 Distance is determined by the return transmit time. 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 113...
  • Page 120 Can be loop powered, analog, intrinsically safe 4 to 20 mA, or a digital (BUS) transmitter. TVT (time varying threshold): a time-varying curve that determines the threshold level above which echoes are determined to be valid. Page 114 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...

  • Page 121: Index

    100 HART 75 requirements 11 distance measurement 38 internal enclosure temperature display 19 echo confidence display 19 level measurement 38 set threshold 61 lock value 47 7ML19985HR02 SITRANS Probe LR – INSTRUCTION MANUAL Page 115...
  • Page 122 72 hazardous areas 100 programming indicator 19 propagation factor 54 zener diode safety barriers 101 quick start programming 24 range extension 60 to obtain reliable echo 94 receiver signal 93 Page 116 SITRANS Probe LR – INSTRUCTION MANUAL 7ML19985HR02...
  • Page 123 For more information www.siemens.com/level www.siemens.com/weighing Siemens AG Subject to change without prior notice Industry Sector 7ML19985HR02 Rev. 2.5 1954 Technology Drive P.O. Box 4225 *7ml19985HR02* © Siemens AG 2011 Peterborough, ON Canada K9J 7B1 Printed in Canada email: techpubs.smpi@siemens.com www.siemens.com/processautomation...

Table of Contents
