Dräger X-am 5000 Instructions For Use Manual
Portable gas detection instrument
Hide thumbs
Also See for X-am 5000:
- Instructions for use manual (292 pages) ,
- Technical manual (72 pages) ,
- Instructions for use manual (400 pages)
Table of Contents
Advertisement
Quick Links
Visit: www.thesafetyequipmentstore.com or besafe@thesafetyequipmentstore.com for sales and service.
Dräger X-am
(MQG 0010)
Gebrauchsanweisung
de
2
Instructions for Use
en
11
Notice d'utilisation
fr
20
Instrucciones de uso
es
30
Instruções de uso
pt
39
Istruzioni per l'uso
it
48
Gebruiksaanwijzing
nl
57
Brugsanvisning
da
66
®
5000
Käyttöohjeet
fi
75
Bruksanvisning
no
84
Bruksanvisning
sv
93
Instrukcja obsługi
pl
102
Руководство по эксплуатации
ru
111
Upute za uporabu
hr
120
Navodilo za uporabo
sl
129
Návod na použitie
sk
138
Návod k použití
cs
147
Инструкция за употреба
bg
156
Instrucţiuni de utilizare
ro
165
Használati útmutató
hu
174
Οδηγιών χρήσης
el
183
Kullanım talimatları
tr
192
使用说明
zh
201
Advertisement
Table of Contents
Related Manuals for Dräger X-am 5000
Summary of Contents for Dräger X-am 5000
- Page 1 Visit: www.thesafetyequipmentstore.com or besafe@thesafetyequipmentstore.com for sales and service. ® Dräger X-am 5000 (MQG 0010) Gebrauchsanweisung Käyttöohjeet Návod k použití Instructions for Use Bruksanvisning Инструкция за употреба Notice d’utilisation Bruksanvisning Instrucţiuni de utilizare ...
- Page 2 1) The Technical Manual and Instructions for Use/data sheets for the sensors used and the Dräger PC software CC-Vision for Dräger X-am 5000 can be downloaded on the product page for the X-am 5000 at the following Internet address: www.draeger.com See also the enclosed Instructions for Use and data sheets for the sensors used.
- Page 3 T4 HC (HBT 0100 type, order no. 83 22 244) (refer to chapter "Replacing the Power pack Measured gas display batteries" on Page 15). The Dräger X-am 5000 is ready for operation. [ + ] key Measured value display Operation...
- Page 4 WARNING test must be performed according to the national regulations. When using a CatEx sensor in the Dräger X-am 5000, a calibration of zero point and sensitivity must be carried out after an impact load that results in Switch on the instrument. The current measured values are shown in the a fresh air display not equal to zero.
- Page 5 Identifying alarms STEL / TWA exposure alarm An alarm is displayed visually, audibly and through vibration in a specific pattern. Intermittent alarm: Display » A2 « and » « (STEL) or » « (TWA) and measured value Concentration pre-alarm A1 alternating: Intermittent alarm: CAUTION...
- Page 6 Activating the Info mode Replacing the batteries / rechargeable batteries In measuring mode, press the [OK] key for approx. 3 seconds. WARNING – If any warning or fault messages exist, the corresponding note or error codes Danger of explosion! are displayed (see Technical Manual).
- Page 7 Charging instrument with NiMH power pack T4 Switch on the instrument and insert it into the calibration cradle – press downwards until it engages. (HBT 0000 type)/ T4 HC (HBT 0100 type Open the test gas cylinder valve to let test gas flow over the sensors. ...
- Page 8 – The display containing the current gas concentration changes with the Press the [OK] key to start the calibration function of this measuring channel, display » OK «. or use the [ + ] key to select another measuring channel (O - vol.
- Page 9 1) The Technical Manual and Instructions for Use/data sheets for the sensors used and the PC software CC-Vision for Dräger X-am 5000 can be downloaded on the product page for the X-am 5000 at the following website: www.draeger.com See also the enclosed Instructions for Battery disposal Use and data sheets for the sensors used.
- Page 10 EN 50271 1) The Technical Manual and Instructions for Use/data sheets for the sensors used and the PC software CC-Vision for Dräger X-am 5000 can be downloaded on the product page for the X-am 5000 at the following website: www.draeger.com See also the enclosed Instructions for Use and data sheets for the sensors used.
- Page 11 Notes on Approval Battery Pack Type ABT 0100 Instructions for Safety Temperature Class T4 To reduce the risk of ignition of a flammable or explo- Marking –20 °C ≤ Ta ≤ +50 °C sive atmosphere, stricly adhere to the following Cau- tion and Warning statements: if used with alkaline batteries Duracell Procell MN1500...
- Page 13 Dräger Safety AG & Co. KGaA Revalstraße 1 D-23560 Lübeck Germany Phone +49 451 8 82- 0 +49 451 8 82- 20 80 www.draeger.com 90 23 896 - GA 4638.210_MUL077 © Dräger Safety AG & Co. KGaA Edition 08 - February 2013 (Edition 01 - April 2007) Subject to alteration...
