Summary of Contents for Dräger X-am 5100

  • Page 1 Visit: www.thesafetyequipmentstore.com or besafe@thesafetyequipmentstore.com for sales and service. ® Dräger X-am 5100 (MQG 0020) Technical Manual...
  • Page 3: Table Of Contents

    Ordering list ......24 Declaration of Conformity ....25 Dräger X-am 5100...
  • Page 4: For Your Safety

    Instructions for Use/data sheets for the utilized sensors and the PC software CC-Vision for Dräger X-am 5100 can be downloaded on the product page of the X-am 5100 at the following Internet address: www.draeger.com. See also the enclosed Instructions for Use and data sheets for the sensors used.
  • Page 5: Description

    Fault message 1-button sensitivity adjustment Warning message Standard sensitivity adjustment Display peak value Password required Show TWA Battery 100 % full Show STEL Battery 2/3 full Bump test mode Battery 1/3 full Fresh air adjustment Battery empty Dräger X-am 5100...
  • Page 6: Tests And Approvals

    Y = 2007, Z = 2008, A = 2009, B = 2010, C = 2011, D = 2012, E = 2013, etc. Example: Serial No. ARCH-0054: the third letter is C, so the year of manufacture is 2011. Dräger X-am 5100...
  • Page 7: Use

    Always connect or disconnect the charging modules individually and not in groups in order to prevent the charging station from becoming damaged. During transportation, the power pack and the charging modules should also always be handled individually and without inserted instruments. Dräger X-am 5100...
  • Page 8 » 3 . 2 . 1 « shown in the display has elapsed. Before the instrument is switched off, the visual, audible  and vibration alarms are activated for a short time. Only when activated in the instrument configuration. Delivery status: not activated. Dräger X-am 5100...
  • Page 9 The instrument is not ready to measure and requires maintenance. 2. Check that the gas inlet opening on the instrument is not covered. Dräger X-am 5100...
  • Page 10: Configuration

    Different settings can be selected to meet customer requirements on delivery. The current setting can be checked and changed with the Dräger CC Vision software. A version of the CC-Vision software that can be used for Dräger X-am 5100 is available for download from the product page for the X-am 5100 at the following web address: www.draeger.com...
  • Page 11: Performing The Bump Test

    (with oxygen, the check is whether the generated. concentration has fallen below the Alarm 1 threshold) and whether the gas concentration has reached the preset bump test concentration. Setting on delivery: Quick bump test.  Dräger X-am 5100...
  • Page 12: During Use

    For remedies, see "Troubleshooting" on page 19 to page 20.  The alarm is indicated by an intermittent alarm Commission maintenance personnel or DrägerService to  message: rectify the error. Display » A2 and measured value alternating. Dräger X-am 5100...
  • Page 13: Menu Functions

    Info Off mode (or via  deleted by pressing the timeout). key for 5 seconds. The next display appears. 2. Press the key to end the function. 10233280.eps Only when activated in the instrument configuration. Delivery status: not activated. Dräger X-am 5100...
  • Page 14: Adjustment Menu

    Press the key to call the selected function.  Press the key to cancel the active function.  If no key is pressed for 10 minutes, the instrument  reverts automatically to measuring mode. Dräger X-am 5100...
  • Page 15: Calibrating The Instrument

    EN 45544-4 – Electrical instruments for the direct detection and direct concentration measurement of toxic gases and vapors – Part 4: Guidelines for selection, installation, use and maintenance. Dräger X-am 5100...
  • Page 16: Performing A Sensitivity Adjustment

    The currently displayed measured values start to flash.  The displayed measured values change to the values  according to the gas supplied. When the measured value is stabilized: 11. Press the key to carry out the calibration. Dräger X-am 5100...
  • Page 17 11333280.eps automatically. The displayed measured values change to the values  according to the gas supplied. The automatic stability monitoring can be terminated by  pressing the key. A calibration then takes place immediately. Dräger X-am 5100...
  • Page 18: Replacing The Sensors

    When the upper shell is being released, it is possible that the DrägerSensor will be pulled out of its mount at the same time and remain in the upper shell. 5. Follow the remaining instructions in the CC Vision PC software. Dräger X-am 5100...
  • Page 19: Troubleshooting

    The temperature is too low Operate the instrument within the allowed temperature range. The calibration interval for DrägerSensor Perform a sensitivity adjustment for XS EC1 has elapsed DrägerSensor XS EC1, see "Calibrating the instrument" on page 15. Dräger X-am 5100...
  • Page 20: Fault Messages

    "Replacing the Sensors" on page 18. Error during accelerated warm-up of Remove the power pack and insert it again or Dräger Sensor XS EC1 replace the sensor. Sensor must not be exposed to gas during the first 5 minutes. Dräger X-am 5100...
  • Page 21: Maintenance

     Instructions for Use/data sheets for the utilized sensors and the PC software CC-Vision for Dräger X-am 5100 can be downloaded on the product page of the X-am 5100 at the following Internet address: www.draeger.com. See also the enclosed Instructions for Use and data sheets for the sensors used.
  • Page 22: Disposal

    Do not throw them into fires or use force to open them. As for batteries, only dispose of as special waste in accordance with local waste disposal regulations. Further information can be obtained from the relevant local authority and from appropriate waste disposal companies. Dräger X-am 5100...
  • Page 23: Technical Data

    130 mm x 48 mm x 61 mm (H x W x D) Weight approx. 220 g to 250 g CE markings Electromagnetic compatibility (Directive 2004/108/EC) Explosion protection (Directive 94/9/EC) Approvals: See “Description” on page 5. Sensor data: See data sheets for the sensors used. Dräger X-am 5100...
  • Page 24: Ordering List

    Ordering list Ordering list Order No. Order No. Name and Description Name and Description Dräger X-am 5100 83 22 750 Accessories for measured value acquisition and configuration: Dräger GasVision 83 14 034 Power supply units: Dräger CC Vision 64 08 515...
  • Page 25: Declaration Of Conformity

    Declaration of Conformity Declaration of Conformity Dräger X-am 5100...
  • Page 28 Visit: www.thesafetyequipmentstore.com or besafe@thesafetyequipmentstore.com for sales and service. Dräger Safety AG & Co. KGaA Revalstraße 1 23560 Lübeck, Germany Tel +49 451 882 0 Fax +49 451 882 20 80 www.draeger.com 90 33 280 - TH 4638.230 © Dräger Safety AG & Co. KGaA Edition 04 - April 2014 (Edition 01 - July 2011) Subject to alteration...
