10 Technical data
134
Dual path version
α
B
Fig. 78: Dimensions of W sensor (Insertion version, dual path)
B = View B
a = Pipe outer diameter (defined by the application)
b = Sensor spacing determinable using Quick Setup
c = Path length determinable using Quick Setup
Π d α
⋅
⋅
-------------------- -
=
Arc length:
L
a
360°
⋅
α
d
sin
------------------- -
=
Offset:
x
2
L
a
B
PROline Prosonic Flow 93
a
Endress+Hauser
