Endress+Hauser PROline prosonic flow 93 Operating Instructions Manual page 100

8 Accessories
100
Accessory Description
Installation set Clamp On Without sensor fastening
sensor fastening for Tensioning bands DN 50...200
Prosonic Flow W/P Tensioning bands DN 200...600
Tensioning bands DN 600...2000
Tensioning bands DN 2000...4000
Installation set Clamp On Without mounting support tool
Installation aids for Spacing ruler DN 50...200
Prosonic Flow W/P Spacing ruler DN 200...600
Mounting rail DN 50...200
Mounting rail DN 200...600
Installation set Clamp On Installation set DN 15...40
sensor fastening for Tensioning bands DN 32...65
Prosonic Flow U Tensioning bands DN 50...100
Installation set Insertion Installation set DN 200...1800, Insertion
Installation set DN 1800...4000, Insertion
Sensor cable set for 5 m sensor cable, PVC, –20...+70 °C
Prosonic Flow W/P sen- 10 m sensor cable, PVC, –20...+70 °C
sors 15 m sensor cable, PVC, –20...+70 °C
30 m sensor cable, PVC, –20...+70 °C
5 m sensor cable, PTFE, –40...+170 °C
10 m sensor cable, PTFE, –40...+170 °C
15 m sensor cable, PTFE, –40...+170 °C
30 m sensor cable, PTFE, –40...+170 °C
Sensor cable set for 5 m sensor cable, PVC, –20...+70 °C
Prosonic Flow U sensors 10 m sensor cable, PVC, –20...+70 °C
15 m sensor cable, PVC, –20...+70 °C
30 m sensor cable, PVC, –20...+70 °C
5 m sensor cable, PTFE, –40...+170 °C
10 m sensor cable, PTFE, –40...+170 °C
15 m sensor cable, PTFE, –40...+170 °C
30 m sensor cable, PTFE, –40...+170 °C
Sensor cable conduit Sensor cable conduit adapter incl. sensor cable
adapter Prosonic Flow glands M20x1.5
W/P Sensor cable conduit adapter incl. sensor cable
glands ½" NPT
Sensor cable conduit adapter incl. sensor cable
glands G½"
Acoustic coupling Coupling medium –40...+80 °C, standard
medium Coupling medium 0...170 °C, standard
Adhesive coupling medium –40...+80 °C
Water-soluble coupling medium –20...+80 °C
SilGel –40...+130 °C
Coupling medium DDU 19 –20...+60 °C
Sound velocity measuring Sensor –40...+80°C
sensor DDU 18 Sensor 0...+170 °C
Wall thickness measuring Sensor for measuring pipe wall thickness
sensor DDU 19
HART Communicator Handheld terminal for remote parameterisation
DXR 375 handheld termi- and for obtaining measured values via the current
nal output HART (4...20 mA).
Contact your E+H representative for more infor-
mation.
PROline Prosonic Flow 93
Order Code
−
DK9IC A*
−
DK9IC B*
−
DK9IC C*
−
DK9IC D*
−
DK9IC E*
−
DK9IC *1
−
DK9IC *2
−
DK9IC *3
−
DK9IC *4
−
DK9IC *5
−
DK9IS A
−
DK9IS B
−
DK9IS C
−
DK9II A
−
DK9II B
−
DK9SC A
−
DK9SC B
−
DK9SC C
−
DK9SC D
−
DK9SC E
−
DK9SC F
−
DK9SC G
−
DK9SC H
−
DK9SK A
−
DK9SK B
−
DK9SK C
−
DK9SK D
−
DK9SK E
−
DK9SK F
−
DK9SK G
−
DK9SK H
−
DK9CA 1
−
DK9CA 2
−
DK9CA 3
−
DK9CM 1
−
DK9CM 2
−
DK9CM 3
−
DK9CM 4
−
DK9CM 5
−
DK9CM 6
50091703
50091704
50091713
−
DXR375 ****
Endress+Hauser
