Installation Guide
1
About documents and decals
1.1
Introduction
The following documents are available for this product:
▪ The Installation Quick Guide is an illustrated step-by-step guide on how to install the heat pump.
Supplied with the heat pump on delivery.
▪ Installation Guide. Complements the Installation Quick Guide and gives thorough information on how to install the heat pump.
Available for download, see below.
▪ The Commissioning Guide contains the required information in order to commission the heat pump and tune the heating system.
Available for download, see below.
▪ The Wiring Diagrams for the heat pump intended for fault tracing and service.
Available for download, see below.
▪ The User Guide is intended for the end user and must be handed over and gone through with the end user when installation and
commissioning is completed.
Supplied with the heat pump on delivery.
▪ Country specific instructions and forms are available where relevant.
Supplied with the heat pump on delivery.
▪ Self-adhesive decals with translation text. Must be placed on the manufacturing plate in conjunction with installation.
Supplied with the heat pump on delivery.
Documents not delivered with the heat pump are available for download here:
www.documentation.heatpump.danfoss.com
1.2
Symbols in documents
The instructions contain different warning symbols, which, together with text, indicate to the user that there are risks involved with ac-
tions to be taken.
The symbols are displayed to the left of the text and three different symbols are used to indicate the degree of danger:
Indicates an immediate danger that leads to fatal or serious injury if
Danger
necessary measures are not taken.
Risk of personal injury!
Warning
Indicates a possible danger that can lead to fatal or serious injury if
necessary measures are not taken.
Risk of installation damage.
Caution
Indicates a possible hazard that can lead to item damage if necessary
measures are not taken.
A fourth symbol is used to give practical information or tips on how to perform a procedure.
Information regarding making the handling of the installation easier
N
or a possible operational technical disadvantage.
Danfoss Heating Solutions
DHP-iQ
VIJSS102
5
