Installation Guide
9 kW and 16 kW
1(L) 2(N)
L
N
15 12
AC power : M5 screw
6.17.3 3-phase terminal block spec
9 kW and 16 kW
1(L) 2(N) L1(R)
9.95
AC power : M4 screw
6.17.4 Connecting the power terminal
▪ Connect the cables to the terminal board using the compressed ring terminal.
▪ Cover a solderless ring terminal and a connector part of the power cable and then connect it.
52
DHP-iQ
L3(T)
L2(S) N
11.55
1
VIJSS102
9.95
Communication : M4 screw
1. Silver solder
9.95
Communication : M4 screw
