- Page 1 UK-specific appendix to Installation instructions DHP-A DHP-A Opti DHP-AQ Maxi DHP-H DHP-H Opti DHP-H Opti Pro DHP-L DHP-L Opti DHP-L Opti Pro VIBMB402 086U8255 Rev 4...
-
Page 2: Table Of Contents
To be read together with Installation instructions Contents Important information/Safety regulations . . . . . . . . . . . . . . . . . . . 3 1 . -
Page 3: Important Information/Safety Regulations
In such circumstances the advice of the local water authority should be sought . The immersion heater, thermostat, and thermal cut-out are supplied by Danfoss and are factory fitted . If a replacement part is necessary, it must be replaced with a Danfoss spare part . -
Page 4: About Documents And Labels
About documents and labels Manufacturer labels The heat pump and the indoor unit are marked with durable, permanently fixed labels . 2.1.1 Manufacturer label: P. O. Box 950 SE-67129 Arvika Sweden DHP-H 6 Heat Pump Source of heat Max System of heat Max Source of heat Min/Max ˚C -10 / +20... - Page 5 2.1.2 Manufacturer label: DHP-AQ P. O. Box 950 SE-671 29 Arvika Sweden DHP-AQ CONTROL MAXI 6-13 SP Heat Pump Source of heat Max System of heat Max Source of heat Min/Max ˚C Refrigerant Type Operation Pressure Min/Max Refrigerant Connection Electric connection 230 1N~50Hz Power input Total 3.1/6.1/9.1...
- Page 6 Weight when full (kg) DHP-H 4 DHP-H 6 DHP-H 8 DHP-H 10 DHP-H 12 DHP-H 16 DHP-A 6 DHP-A 8 DHP-A 10 DHP-A 12 *) Incl. DHP Opti and Opti Pro Maximum water supply pressure 10 bar Pressure reducing valve...
- Page 7 2.1.4 Additional label: DHP-AQ Control Maxi 6–13 SP This label will ensure that this product conforms to the requirements of United Kingdom Building Regulations and EN12897:2006. The information is entirely valid in a UK specific installation. Weight when full 286 kg PT valve replacement no.
-
Page 8: Piping Installation
Piping installation General In section 5 .2 you will find connection diagrams . 3.1.1 Unvented package DHP and DWH200 Danfoss code reference UNV0180 . Package contents: Position Danfoss code Number Description FITT0050 Expansion vessel 19 liter FITT0052 Expansion vessel bracket... -
Page 9: System Solution
Flexible hose Unvented package ) The water heater tank in DHP-H and DHP-A models is factory fitted with a Temperature and pressure relief valve . The connection from this valve must not be used for other purposes other than discharge pipe con- nection . - Page 10 3.2.2 Unvented package installation, DHP-L models, DWH 200, DWH 300 10 11 Unvented manifold assembly (see figure 1) DWH 200 DHP-L DWH 300 Figure 4. The principal installation solution of the unvented package on DHP-L models together with DWH. Position Name Supply line heating system Return line heating system...
- Page 11 3.2.3 Unvented package installation, DHP-L Opti Pro models, DWH 200, DWH 300 Unvented manifold assembly (see figure 1) DWH 200 DHP-L Opti Pro DWH 300 Figure 5. The principal installation solution of the unvented package on DHP-L Opti Pro models with DWH Position Name Supply line heating system...
- Page 12 3.2.4 Unvented package installation, DHP-AQ Maxi 10 11 Unvented manifold assembly (see figure 1) DHP-AQ Maxi Figure 6. The principal installation solution of the unvented package on DHP-AQ Maxi Position Name Heat pump unit Supply line heating system Return line heating system Cold water Hot water Flow guard...
-
Page 13: Discharge Pipe Arrangement
Discharge pipe arrangement DD B D The tundish must be positioned away from any electrical devices . The tundish must be installed so that it is visible to the occupants . 600 mm maximum 300 mm minimum Figure 7. The principal installation solution of the discharge pipe assembly. Position Name Safety device (for example, temperature relief valve) -
Page 14: Commissioning
Commissioning How to flush the tap water system When the tap water and the heating system have been filled up, the unit shall be running at maximal, nor- mal operating temperature for a minimum of one hour . After that the tap water system shall be flushed out and re-filled . - Page 15 Appendix UK – 15...
