Delivery check

Check that the delivery contains the following components:
Quantity Heat pump (Outdoor unit)
1 Document set
1 Package (drain plug, rubber leg)
1 Flow switch (black screw nut)
1 Filter ball
Tab. 1: 5 kW
1
1. You will find the accessory parts in this box.
Quantity Heat pump (Outdoor unit)
1 Document set
1 Package (drain plug, rubber leg, drain
caps)
1 Flow switch (red screw nut)
1 Filter ball DN25 086L0401
1 Rubber bushing M32 086L3147
1 Rubber bushing M20 086U0144
Tab. 2: 9 and 16 kW
1
2
4.3

Installing the unit

Moving the unit
▪ Do not slant the product more than 30˚when carrying it. (do not lay the product down sideways)
▪ Select the moving route in advance.
Danfoss Heating Solutions
DHP-iQ
Indoor unit DHP-iQ Mini
1 Outdoor sensor (NTC)
3 Pipe sensors (NTC)
Indoor unit DHP-iQ Mini
1 Outdoor sensor (NTC)
3 Pipe sensors (NTC)
1
2
Indoor unit DHP-iQ Maxi
1 Outdoor sensor (NTC)
2 Rubber sleeves
Indoor unit DHP-iQ Maxi
1 Outdoor sensor (NTC)
2 Rubber sleeves
1. Pull the side of the cover downward, after loosen the screws.
2. Pull the smaller cover straight up after loosen the screw and
you will find the accessory parts behind the cover.
