Installation Guide
DHP-iQ
When the air outlet is opposite the wall. (300 mm or more)
When 3 sides of the outdoor unit are blocked by the wall (300/600 mm or more)
300
600
300
The upper part of the outdoor unit and the air outlet is opposite the wall (300/600 mm or
more)
When the air outlet is towards the wall: (1500 mm or more)
2000
The upper part of the outdoor unit and the air outlet is towards the wall (1500/2000 mm
or more)
When front and rear side of the outdoor unit is towards the wall (300/1500 mm or more)
Danfoss Heating Solutions
VIJSS102
31
