Installation Guide
Do not install the heat pump in following places:
▪ The place where there is mineral oil or arsenic acid. There is a chance that parts may get damaged due to burned resin. The capacity
of the heat exchanger may reduce or the Air to Water Heat pump may be out of order.
▪ The place where corrosive gas such as sulfurous acid gas generates from the vent pipe or air outlet. The copper pipe or connection
pipe may corrode and refrigerant may leak.
▪ The place where there is a danger of existing combustible gas, carbon fiber or flammable dust. The place where thinner or gasoline
is handled.
N
Caution
If the outdoor unit is installed at a height, ensure that its base is firmly fixed in position. Make sure that the water dripping from the drain
hose runs away correctly and safely.
When you install the outdoor unit at wayside, you should install it above 2m height or make sure that the heat from the outdoor unit
shouldn't be in direct contact with passersby. (The ground for application :The revision of regulation for facility in building by the law of
the Ministry of Construction and Transportation.
4.6.1

Space requirements for outdoor unit

Space requirements for positioning one outdoor unit
Our units shall be installed in compliance with the spaces described in the installation manual, to ensure accessibility from both sides
and allow repairs or maintenance operations to be carried out. If the units installed without complying with procedures described in
manual, additional expenses can be asked because special harnesses, ladders, scaffolding or any other elevation system for repair serv-
ice will NOT be considered part of the warranty and will be charged to the end customer.
N
Caution
Caution
30
DHP-iQ
Adhere to national regulations regarding noise interference.
This device must be installed according to the national electrical rules.
With an outdoor unit having net weight upper than 60kg, we suggest
do not install it suspended on wall, but considering floor standing one
The heat pump should not be enclosed.
Incorrect positioning of the heat pump risks reduction of performance.
The units must be installed according to distances declared, in order
to permit accessibility from each side, either to guarantee correct op-
eration of maintenance or repairing products. The unit's parts must be
reachable and removable completely under safety condition (for peo-
ple or things).
VIJSS102 Danfoss Heating Solutions
