Seagull Models SEAX139 Assembly Manual page 5

3) Use a drill bit to drill the holes for the ser-
vo mounting screws.
4) Use a screwdriver to thread a servo
mounting screw into each of the holes to cut
threads in the surrounding wood. Remove
the screw before moving to the next step.
5) Apply 2-3 drops of thin CA in each of the
holes to harden the surrounding wood. This
will harden the threads so the screws do not
easily strip the surrounding wood.
C/A glue.
WWW.SEAGULLMODELS.COM
1.5mm
6)Secure the servo using the screws provided
with the servo and a screwdriver. The output
shaft of the servo will align with the opening
in the cover.
7) Fit the servo horn to the servo so it is per-
pendicular to the servo.
8) Use string or dental floss to secure a servo
extension to the aileron servo lead.
9) Use the string to pull the extension
through the wing root.
5
