2. System Reference

Specifications

Table 2.1. Functional Specifications < 1 / 2 >
Model
CPU
Chip set
BIOS
Memory
Graphics Controller
Display I/F
System Analog RGB
resolution
DVI-D
HDMI
Audio
Serial ATA I/F
CFast slot
Serial I/F
RAS WDT
function
Remote reset Isolated digital input
General-
purpose I/O
*1 : The capacity of storage device is a value when 1GB is calculated by one billion bytes. The capacity that can be
recognized from OS might be displayed fewer than an actual value.
BX-1000 User's Manual
BX-1000xx-AC37xxx
Intel® Core™ i7-3517UE 1.70GHz
Intel® QM77
BIOS (mfd. by Award)
4GB, 204pin SO-DIMM socket x 2, PC3-10600(DDR3 1333)DDR3 SDRAM support
Intel® HD Graphics 4000 (CPU integrated)
Analog RGB I/F x 1 (15pin HD-SUB connector x 1), DVI-D x 1 (25pin DVI-D connector),
HDMI x 1
640 x 480, 800 x 600 , 1,024 x 768, 1,152 x 864, 1,280 x 600, 1,280 x 720, 1,280 x 768,
1,280 x 800, 1,280 x 960, 1,280 x 1,024, 1,360 x 768, 1,366 x 768, 1,400 x 1,050, 1,440 x 900,
1,600 x 900, 1,680 x1,050, 1,920 x 1,080, 1,920 x 1,200 (16,770,000 colors)
640 x 480, 800 x 600 , 1,024 x 768, 1,152 x 864, 1,280 x 600, 1,280 x 720, 1,280 x 768,
1,280 x 800, 1,280 x 960, 1,280 x 1,024, 1,360 x 768, 1,366 x 768, 1,400 x 1,050, 1,440 x 900,
1,600 x 900, 1,680 x1,050, 1,920 x 1,080, 1,920 x 1,200 (16,770,000 colors)
640 x 480, 800 x 600 , 1,024 x 768, 1,152 x 864, 1,280 x 600, 1,280 x 720, 1,280 x 768,
1,280 x 800, 1,280 x 960, 1,280 x 1,024, 1,360 x 768, 1,366 x 768, 1,400 x 1,050, 1,440 x 900,
1,600 x 900, 1,680 x1,050, 1,920 x 1,080, 1,920 x 1,200 (16,770,000 colors)
HD Audio compliant, LINE OUT x 1, LINE IN x 1, MIKE IN x 1
Slot-in 2.5 inches SATA hard disk x 2 Serial ATA 3.0 compliant support
RAID 0/1 support
Windows 7 Professional pre-install model : SATA HDD is finished mounting
(100GB, one partition) *2
The other model : It is not mounted.
one slot, CFast CARD Type I x 1 bootable
Windows Embedded Standard2009 pre-install model : CFast is finished mounting
(8GB, one partition) *1
Windows Embedded Standard7 pre-install model : CFast is finished mounting
(16GB, one partition) *1
The other model : It is not mounted.
RS-232C (general-purpose) : 3ch (SERIAL PORTA, B, C) 9pin D-SUB connector (male)
Baud rate : 50 - 115,200bps
Software programmable ,255 level(1sec - 255sec)
Time up allows reset
3 isolated inputs and outputs
BX-1000
Intel® Celeron™ 927UE 1.50GHz
Intel® HD Graphics (CPU integrated)
9pin D-SUB connector (male)
2. System Reference
BX-1000xx-AC17xxx
