1. Introduction

Features

- Adoption of ultra-low voltage processor Core i7-3517UE (1.70GHz) or Celeron 927UE (1.50GHz),
QM77 chip set, and 4GB of memory
These products has the power-saving high-performance, ultra-low-voltage processor Core i7-3517UE
(1.70GHz) or Celeron 927UE (1.50GHz), QM77 chip set, and 4GB DDR3 SDRAM memory, achieve a
high-level computing and drawing ability. The adoption of an embedded-type CPU and chipset enables
a stable power supply.
- Industrial BOX-PC equipped with a rich variety of interfaces
This product is equipped with a rich variety of interfaces such as an analog RGB, DVI-D, HDMI, USB
3.0 × 4 *1, USB 2.0 × 2, 1000BASE-T × 2, serial (RS-232C) × 3, DIO, and audio.
- Intel® Ivy Bridge processor series support
This product supports the Intel® Ivy Bridge processor series, and two types of CPUs can be selected to
match various applications.
- Intel® Core i7-3517UE
- Intel® Celeron 927UE
- Adoption of slot-in 2.5 inches SATA hard disk bay unit
Slot-in method is adopted allowing easy install / removal.
- Expansion slots to hold PCI bus boards (Model with Expansion Slot).
BX-1000P2 has two PCI slots.
BX-1000P4 has one PCI-Express(x8) slot and three PCI slots.
- Fan-less operation achieved by natural air-cooling
The use of a power-saving CPU and naturally-cooled cabinet structure allows fanless operation.
- Clamps prevent problems caused by cable disconnections
Unnecessary trouble can be avoided by the use of clamps for prevention of cable disconnection.
- Installation-compatible with conventional products in the IPC-BX 900 / 710 series
For the installation-compatible with conventional products in the IPC-BX 900 / 710 series, it is easy to
migrate from the existing system.
- Safety design required for embedded applications
For Windows Embedded Standard installed model, it is possible to use the EWF *2 function of OS. It is
designed for safety required for embedding purpose, for example, prohibiting unwanted writing to the
storage device with EWF function will relieve the concern about the writing limits to the storage device
and prevent an unintentional system alteration.
*1 The Windows Embedded Standard 2009 model does not support USB 3.0. The USB 3.0 ports operate as USB 2.0
ports.
*2 EWF (Enhanced Write Filter) is a function specific to Windows Embedded Standard that protects the disk from being actually written
by redirecting the writing to RAM.
