5.12. Send message
The <address> field is the address of the terminal network to whom the
message is sent ; <exitmethod> is ^Z : ASCII 26. The text can contain all
existing character except ^Z.
Example of use :
Application to GSM
GSM to application
Application to GSM
GSM to application
The message reference <mr> which is returned back to the application is
allocated by the GSM module. This number begins with 0 and is incremented
by one for each outgoing message (successful and failure case) ; it is cyclic
on one byte (0 follows 255).
Note : this number is not a storage number - outgoing messages are not
stored.
5.13. Set Text Mode Parameters
This command shall be used to select value for the <vp>, <pid>, the
<dcs>. The application must send the following command :
In text mode <vp> is coded only in "relative" format. This means one
octet (see document [4] for more details).
Application to GSM
GSM to application
Application to GSM
GSM to application
This confidential document is the property of WAVECOM and may not be copied or circulated without permission
+CMGS
AT+CMGS="+33146290800"<CR>
Hello, how are you ?^Z
+CMGS : <mr>
OK
AT+CMGS=<length><CR>
<pdu>^Z
+CMGS : <mr>
OK
AT+CSMP=<fo>, <vp>, <pid>,<dcs>
AT+CSMP?
+CSMP: 0,0,0,0
OK
AT+CSMP=16,32,64,244
OK
Send a message in text
mode
Successful transmission
Send a message in PDU
mode
Successful transmission
+CSMP
current values
no validity period
dcs = PCCP437 alphabet
( 8 bits -> 7 bits )
validity period = 32
dcs = GSM 8 bits alphabet
command correct
37
