Before starting the Setup

Make the following preparations before starting Setup.
•
Check that all of the items included in the package. (Please see in the FCX2000 User's Manual (PDF).)
For the Parts Names, please see in the FCX2000 User's Manual (PDF).
•
Assemble the stand and then install the FCX2000. See the instruction manual supplied with the stand for the assembling
procedures.
•
To use the Cutting Master 4, previously install the design application (Adobe Illustrator or CorelDraw ) that is used.
For the latest supported version, please visit our website.
•
When there are virus detection program or system resident program, terminate them beforehand.
•
Upon installation, be sure to log in Windows/Macintosh using an account with administrator privileges on your computer.

Setup flow

Setting up the Plotter main unit
1. Attaching a Tool
2. Loading the Media
3. About the Initial Setup screen
4. Tool adjustment and test cutting
Installing the Software
•
Setup in a Windows operating environment
Launching the Start menu
A. Install FCX2000 Software
Installing the FCX2000 Driver (Cutting
Plotter Driver)
• To connect using the USB
Install the software as necessity.
B. Setup the Graphtec Pro Studio
C. Setup the Cutting Master 4
D. Install the User's Manual
•
Setup in a Macintosh operating environment
A. Setup the Cutting Master 4
B. Setup the Graphtec Studio
The cutter blade can replaced depending on the material or thickness of the
media.
Set up the media in the Plotter.
Select "Display Language" and "Length Unit".
Adjust the tip length of the cutter blade and force (pressure to cut) depending on the material or
thickness of the media. By cutting to test the set media, it can be adjusted to the optimal condition.
For each software of FCX2000, install them using the Installer stored in the
attached DVD-ROM.
The FCX2000 Driver software controls the Plotter and makes plotting
according to the data created by the PC.
Turn on the power source of Plotter in the middle of installing, and connect the USB cable.
Software enabling cutting data to be created through simple commands.
Create designs and edit characters/shapes using this software.
Plug-in driver that enables simple cutting through direct operation from within
Adobe Illustrator and CorelDRAW.
Install the FCX2000 User's Manual.
Plug-in driver that enables simple cutting through direct operation from within
Adobe Illustrator.
Software enabling cutting data to be created through simple commands.
Create designs and edit characters/shapes using this software.
2
P.03
P.04
P.05
P.05
P.07
P.09
P.09
P.10
P.13
P.15
P.15
P.18
