GRAPHTEC FCX2000 SERIES Setup Manual page 9

A. Install FCX2000 Software
If you are using the FCX2000 for the first time, click on [Install
FCX2000 Software] to install the device.
This operation will install the [Plotter Driver].
Note
Do not connect the accompanying USB cable yet.
Doing so may prevent the [Plotter Driver] from being
installed properly.
Refer to the procedures in this User's Manual when
connecting the USB cable.
Installing the [Plotter Driver]
1
Click on [Install FCX2000 Software].
After a while, the "Setup" screen of "Graphtec FCX2000
driver" will be displayed.
Click on [OK].
2
Next, check to make sure the FCX2000 is not connected
to your computer, then click on [Next].
3
Click on [Next] again.
4
Select the [Port Name] to be used.
Here, select [USB].
Clicking on [Next] will begin the driver installation
process.
USB : Selected when a USB cable is used for
connection.
COM1 : Selected when an RS-232C (serial) cable is
used for connection.
FILE : Selected to save outputted data (plot data) to
a file.
Standard TCP/IP Port :
Connect using a LAN cable.
Supplement (When selecting the COM1)
To select "COM1" in "Selecting Port Name", do the
installation according to the message.
(For more information about connecting the RS-232C cable,
see "Connecting the computer" in User's Manual (PDF).)
Supplement (When selecting the Standard TCP/IP Port)
When selecting the "Standard TCP/IP Port" in the "Select
port name", install it according to the message.
Connect the network cable after installing it. (See
"Connecting to the Computer" in the User's Manual (PDF)
for more information on how to connect the network cable.)
IP address depends on the network environment. Please
consult your network administrator. See "Setting the
Interface" in the User's Manual (PDF) for more information
on how to check the IP address of this device.
5
The "Windows Security" screen will appear momentarily.
Click on [Install] to install the [Plotter Driver].
6
Next, the "Graphtec FCX2000 driver installation
completed" screen will appear.
Click on [OK] to reboot your computer.
This concludes the installation of the [Plotter Driver].
After rebooting your computer, follow the below procedures to
connect the USB cable.
9
Select "USB"
