1.4.2
Watchdog Timer
There is a built-in watchdog timer in UNO-1251G. Users can utilize the WDT driver
with standard WIN32 API to implement the watchdog function in their applications. To
use the watchdog driver, firstly users must open "WDT1:", then use the DeviceIO-
Control function to access the watchdog hardware. The introduction below includes
the definition of DeviceIOControl and its parameters as well as an example.
How to Use the Control Code
There are 9 control codes for the operation codes in the WDT driver.
1. IOCTL _WDT_ENABLE:
Enable the Watchdog timer on your application. By default, if the Watchdog timer is
enabled, the WDT driver will automatically reload the timeout counter after a speci-
fied period and your application does not need to trigger the strobe periodically for
masking the timeout, unless use IOCTL_WDT_REBOOT timeout to stop this auto-
matic strobe triggering.
lpInBuffer: unused.
nInBufferSize: unused.
lpOutBuffer: unused.
nOutBufferSize: unused.
2. IOCTL _WDT_DISABLE:
Disable the Watchdog timer on your application.
lpInBuffer: unsed.
nInBufferSize: unused.
lpOutBuffer: unused.
nOutBufferSize: unused.
3. IOCTL_WDT_STROBE:
Trigger strobe signal to reload watchdog timeout counter. If your application uses
IOCTL_WDT_ENABLE
IOCTL_WDT_REBOOT to the WDT driver, your application must trigger the Watch-
dog once during the Watchdog timer period. If your application has not triggered at
the specified period, the device will re-boot automatically.
lpInBuffer: unused.
nInBufferSize: unused.
lpOutBuffer: unused.
nOutBufferSize: unused.
4. IOCTL_WDT_GET_TIMEOUT:
Get the Watchdog timeout value.
lpInBuffer: unused.
nInBufferSize: unused.
lpOutBuffer: The DWORD pointer to your Watchdog timeout setting. The Watchdog
timeout setting is just a number. 0 means 2 seconds, 1 means 5 seconds, 2 means
10 seconds, 3 means 15 seconds, 4 means 30 seconds, 5 means 45 seconds, 6
means 60 seconds, 7 means 120 seconds,8 means 300 seconds, 9 means 600 sec-
UNO-1251G Software User Manual for WEC7
to
enable
the
Watchdog
14
first
and
then
sends
