- Page 1 User Manual UNO-238 V2 電腦 ® Intel Alder Lake processor IoT Edge Computer, with 2 x LAN, 2 x COM, 2 x CAN, 4 x USB, 2 x Type-C, 1 x DP, 1 x HDMI, 1 x GPIO, 3 x M.2 B/M/E Key...
- Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
- Page 3 UNO238C7N2902-T, Product Warranty (2 years) Advantech warrants the original purchaser that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products that have been repaired or altered by persons other than repair personnel authorized by Advantech, or products that have been subject to misuse, abuse, accident, or improper installation.
- Page 4 This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This type of cable is available from Advantech. Please contact your local supplier for ordering information.
- Page 5 This equipment is not suitable for use in locations where children are likely to be present. If the equipment is used in a manner not specified by the Advantech, the protec- tion provided by the equipment may be impaired. UNO-238 V2 User Manual...
- Page 6 Do not block air ventilation holes. This is open type equipment and should be installed in a suitable enclosure. DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
- Page 7 電源線或者插頭損壞； 設備內部有液體流入； 設備曾暴露在過於潮濕的環境中使用； 設備無法正常工作，或您無法通過用戶手冊來使其正常工作； 設備跌落或者損壞； 設備有明顯的外觀破損。 請不要把設備放置在超出我們建議的溫度範圍的環境，即不要低於 -20°C （- 4°F）或高於 60°C （140°F)） ，否則可能會損壞設備。 注意：若電池更換不正確，將有爆炸危險。因此，只可以使用製造商推薦的同一 種或者同等型號的電池進行替換。請按照製造商的指示處理舊電池 根據 IEC 704‐1:1982 規定，操作員所在位置音量不可高於 70 分貝。 限制區域：請勿將設備安裝於限制區域使用。 免責聲明：請安全訓示符合 IEC 704‐1 要求。研華公司對其內容之準確性不承 擔任何法律責任。 消费者若使用电源适配器供电，则应购买配套使用获得 CCC 认证并满足标准要 求的电源适配器。 UNO-238 V2 User Manual...
- Page 8 限用物質含有情況標示聲明書 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱：電腦 型號 （型式） ：UNO-238 V2 ( 系列型號請參見手冊載明型號） Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 六價鉻 多溴聯苯 多溴二苯醚 單元 Unit 鎘 Hexavalent 鉛 Lead 汞 Mercury...
-
Page 9: Table Of Contents
Chapter Hardware Functionality.......7 Introduction ....................8 Figure 2.1 Key components locations of UNO-238 V2 (top side) 8 Figure 2.2 Key components locations of UNO-238 V2 (bottom side)................8 Table 2.1: Key components, connectors on board ...... 9 External I/O Connectors................10 Figure 2.3 Front I/O of UNO-238 V2......... - Page 10 M.2 M Key 2280 (M2_2) ............. 31 Table A.3: ................. 31 TPM 2.0 BIOS Setting................33 CPU Turbo mode BIOS Setting .............. 34 Serial Port 1 Configuration..............36 Serial Port 2 Configuration..............38 GPIO Configuration................. 40 CANBus Configuration ................42 UNO-238 V2 User Manual...
-
Page 11: Chapter 1 Overview
Chapter Overview This chapter provides an overview of the UNO-238 V2 specifications. Sections include: Introduction Safety precautions Accessories Hardware Specifications Dimensions... -
Page 12: Introduction
Introduction Advantech’s new UNO-200 series focuses on IT level applications, which only require semi-industrial design and cost efficiency. New UNO-238 V2 model aims to ® provide an optimized design with the 12th generation CPU Intel Core™ Alder Lake P-Series processor. UNO-238 V2 is IT-oriented, fanless, with IoT edge computing features and sufficient connectivity including 2 x LAN, 2 x RS- 232/ 422/485, 1 x GPIO, 4 x USB 3.2, 2 x USN Type-C 1 x DP 1.4, 1 x HDMI 2.0 and 1 x CANBus. -
Page 13: Accessories
1 x Thermal grease for CPU (Advantech P/N: 2170000093-01) 1 x Earth-ground cable (Advantech P/N: 1703011001-11) 1 x Bracket for 3042/3052 LTE module (Advantech P/N: 1960098471N000) 2 x Screws for attaching 3042/3052 bracket (Advantech P/N: 1930001782) ... -
Page 14: System Hardware
- 40 ~ 85°C (-40 ~ 185°F) Relative Humidity 10 ~ 95% RH @ 40 °C/104 °F, non-condensing Shock Protection Operating, IEC 60068-2-27, 50G, half sine, 11ms Vibration Protection Operating, IEC 60068-2-64, 2 Grms, random, 5 ~ 500 Hz, 1hr/axis UNO-238 V2 User Manual... -
Page 15: Certification
1.4.5 Certification Table 1.5: Certification Certification CE/FCC, CB/UL, CCC, BSMI Mechanical Specifications 1.5.1 Dimensions 162.00 150.00 107.00 Figure 1.1 UNO-238 V2 dimensions UNO-238 V2 User Manual... - Page 16 UNO-238 V2 User Manual...
-
Page 17: Chapter 2 Hardware Functionality
Chapter Hardware Functionality This chapter explains how to setup the UNO-238 V2 hardware func- tions, including connecting periph- erals and indicators. Sections include: Introduction External I/O Connector Internal I/O Connector LED Indicators Reset Buttons Antenna Hole... -
Page 18: Introduction
The following figure shows the locations of key components, internal and the external connectors on motherboard of UNO-238 V2. Figure 2.1 Key components locations of UNO-238 V2 (top side) Figure 2.2 Key components locations of UNO-238 V2 (bottom side) UNO-238 V2 User Manual... - Page 19 M.2 Key B Connector for Storage (SSD) or LTE/5G M2_1 M.2 Key E Connector for Wi-Fi M2_2 M.2 Key M Connector for Storage (NVMe) DDR5 SO-DIMM 5.2mm DDR5 SO-DIMM 9.2mm BAT1 RTC Battery Connector AT mode/Load BIOS default UNO-238 V2 User Manual...
-
Page 20: External I/O Connectors
External I/O Connectors Figure 2.3 Front I/O of UNO-238 V2 Figure 2.4 Right I/O of UNO-238 V2 Figure 2.5 Rear I/O of UNO-238 V2 UNO-238 V2 User Manual... -
Page 21: Power Connector
It can also be enabled/disabled in the BIOS menu. 2.2.4 DisplayPort Connector UNO-238 V2 provides 1 x DP 1.4 connector for a high resolution interface up to 4096 x 2160 @ 60Hz. 2.2.5 HDMI Connector UNO-238 V2 provides 1 x HDMI 2.0 connector for a high resolution interface up to... -
Page 22: Com Connector
2.2.6 COM Connector UNO-238 V2 features 2 x RS232/422/485 ports (Combo) extender from COM port from COM1/COM2 function through a cable. Table 2.2: COM Connector Pin Assignments Signal Pin Definition COM1_CTS_T-_D- COM1_RXD_T+_D+ COM1_TXD_R+ COM1_RTS_R- COM2_CTS_T-_D- COM2_RXD_T+_D+ COM2_TXD_R+ COM2_RTS_R- UNO-238 V2 User Manual... -
Page 23: Gpio Connector
2.2.7 GPIO Connector UNO-238 V2 features 1 x GPIO port extender from GPIO from CN5 function through a cable. Table 2.3: GPIO Connector Pin Assignments Signal Pin Definition pin1 GND GPIO0 GPIO1 GPIO2 GPIO3 GPIO4 GPIO5 GPIO6 GPIO7 2.2.8 CAN Connector UNO-238 V2 supports 2 x CANBus terminal block from CN2/CN3 function through a cable for line out function. -
Page 24: Internal I/O Connector And Switch
The following figure shows the locations of internal connectors and switches on the mother board of UNO-238 V2. Figure 2.6 Internal I/O connector and switch (top side) of UNO-238 V2 Figure 2.7 Internal I/O connector and switch (bottom side) of UNO-238 V2... -
Page 25: Connector
2.3.1 M.2 Connector UNO-238 V2 provides 1 x M.2 B Key 2242/3042/3052 connector, 1 x M.2 E Key 2230 and 1x M.2 M Key 2280 connector for storage (M-key supports NVMe PCIex4) while M.2 B key 3042/3052 is for LTE/5G module, 2242 is for storage (supports PCIe/SATA as well as USB 2.0). -
Page 26: Others
Green Orange 2.4.2 Power Button UNO-238 V2 features 1 x power button extend from LED function through cable. Press the power button to activate the hardware power on and shut down function. 2.4.3 Antenna Hole This product offers four antenna mounting holes covered by pre-cut holes for users to install with an antenna kit if LTE or wireless functions are needed. -
Page 27: Initial Setup
Chapter Initial Setup This chapter explains how to Initial- ize the UNO-238 V2. Sections include: Chassis Grounding Connecting Power Storage Installation (Optional) -
Page 28: Chassis Grounding
Chassis Grounding UNO-238 V2 provides good EMI protection and a stable grounding base. There is an easy-to-connect chassis grounding point to use. Figure 3.1 Chassis grounding connection Use the Earth-Ground cable (16 AWG) from accessory bag to connect the chassis ground with the Earth ground. -
Page 29: Install Ddr And Thermal Pad
Install DDR and Thermal Pad Unscrew (1930001241-11*4) and remove BTM cover (1960098469N011*1). Unscrew (1930004041*4). UNO-238 V2 User Manual... - Page 30 Unscrew (1930001241-11*4) and remove top cover (1960098692T011*1). Paste Thermal pad (1990040074N000*1). For DDR5 8/16G use Paste Thermal pad (1990026727N020*1) Paste Thermal pad (1990040197N010*1) UNO-238 V2 User Manual...
- Page 31 For DDR5 32G use Paste Thermal pad (1990026184N010*1) Paste Thermal pad (1990040197N000*1) Install Top cover (1960098692T011*1) and Lock screw (1930001241-11*4). Lock screw (1930004041*4). UNO-238 V2 User Manual...
-
Page 32: Din-Rail Installation Mounting
Install BTM cover (1960098469N011*1) and Lock screw (1930001241-11*4). Din-Rail Installation Mounting Please refer to UNO-238 V2 Startup Manual. Install SMA Unscrew (1930001241-11*4) and Remove BTM cover(1960098469N011*1). UNO-238 V2 User Manual... -
Page 33: Bios Setting
BIOS setup screen, then, press the Del key during the Power On Self Test (POST) process to enter the BIOS setup screen, otherwise the system will con- tinue the POST process. (Please refer to User Manual- Appendix for more settings) UNO-238 V2 User Manual... - Page 34 UNO-238 V2 User Manual...
-
Page 35: Appendix A System Settings/Pin Assignments
Appendix System Settings/Pin Assignments... -
Page 36: M.2 Connector
M.2 Connector A.1.1 M.2 B Key 2242/3042/3052 (M2_B1) Table A.1: M.2 B Key Signal Pin Definition (Key B) M2B1_CFG3 +V3.3A_M.2_B +V3.3A_M.2_B M2B1_FULL_CARD_OFF# USB_M2B1_P M2B1_WDIABLE1# USB_M2B1_N M2B1_LED1# M2B1_PCIE_DIS UNO-238 V2 User Manual... - Page 37 Table A.1: M.2 B Key M2B1_CFG0 M2B1_ANT_CFG M2B1_WAKE_ON_WWAN# M2B1_ANT_TUNER M2B1_DPR M2B1_W_DISABLE2# M2B1_UIM_RESET M2B1_UIM_A_CLK M2B1_UIM_ DATA M2B1_UIM _PWR 43M2B1_PCIE_RX- 43M2B1_PCIE_RX+ M2B1_PCIE_TX- M2B1_PCIE_TX+ M2B1_PREST# M2B1_A_CLKREQ# CLK100M_A_M2B1- M2B1_PCIEWAKE# CLK100M_A_M2B1+ M2B1_A_RESET# UNO-238 V2 User Manual...
-
Page 38: E Key 2230 (M2_1)
Table A.1: M.2 B Key M2B1_SUSCLK M2_SATA1B_PEDET +V3.3_M.2_B +V3.3_M.2_B +V3.3_M.2_B A.1.2 M.2 E Key 2230 (M2_1) Table A.2: M.2 E Key Signal Pin Definition (Key E) +V3.3SB_M.2_E USB6_Z_P+ +V3.3SB_M.2_E USB6_Z_P- UNO-238 V2 User Manual... - Page 39 Table A.2: M.2 E Key PCIE_M2_Z_TX7+ PCIE_M2_Z_TX7- PCIE_M2_RX11+ PCIE_M2_RX11- CLK_M2E_Z_PCIE+ CLK_M2E_Z_PCIE- SUSCLK_Z_EKEY PLTRST_BUFFER# PCIE_A_CLKREQ2 BT_DISABLE# PCIE-WAKE# WIFI_DISABLE UNO-238 V2 User Manual...
- Page 40 Table A.2: M.2 E Key +V3.3SB_M.2_E +V3.3SB_M.2_E UNO-238 V2 User Manual...
-
Page 41: M.2 M Key 2280 (M2_2)
A.1.3 M.2 M Key 2280 (M2_2) Table A.3: Signal Pin Definition (Key E) +V3.3_M.2 +V3.3_M.2 PCIE4_KEY-M_RX3- PCIE4_KEY-M_RX3+ M.2 PLN# PCIE4_KEY-M_A_TX3- +V3.3_M.2 PCIE4_KEY-M_A_TX3+ +V3.3_M.2 UNO-238 V2 User Manual... - Page 42 Table A.3: +V3.3_M.2 PCIE4_KEY-M_RX2- +V3.3_M.2 PCIE4_KEY-M_RX2+ PCIE4_KEY-M_A_TX2- PCIE4_KEY-M_A_TX2+ PCIE4_KEY-M_RX1- PCIE4_KEY-M_RX1+ PCIE4_KEY-M_A_TX1- PCIE4_KEY-M_A_TX1+ PCIE4_KEY-M_RX0- PCIE4_KEY-M_RX0+ PCIE4_KEY-M_a_TX0- PCIE4_KEY-M_a_TX0+ PLTRST_MKEY_BUFFER# CLK2_M2MB_a_PCIE_REQ# CK_100M_a_MKEY_N M.2_PCIE_WAKE# CK_100M_a_MKEY_P PCH_SUSCLK_R_MKEY UNO-238 V2 User Manual...
-
Page 43: Tpm 2.0 Bios Setting
UNO-238 V2 systems support TPM2.0 functionality. This can be enabled or disabled in the BIOS menu by following the instructions provided below. Power on the UNO-238 V2 system and press “Delete” to enter the BIOS config- uration menu. On the “Advanced” tab, select the “Trusted Computing” item. -
Page 44: Cpu Turbo Mode Bios Setting
CPU Turbo mode BIOS Setting The UNO-238 V2 systems support CPU Turbo mode. This can be enabled or dis- abled in the BIOS menu by following the instructions provided below Power on the UNO-238 V2 system and press “Delete” to enter the BIOS config- uration menu. - Page 45 UNO-238 V2 User Manual...
-
Page 46: Serial Port 1 Configuration
Serial Port 1 Configuration The UNO-238 V2 systems support Serial port 1 RS-232/RS-422/RS-485 mode. Power on the UNO-238 V2 system and press “Delete” to enter the BIOS config- uration menu. On the “Advanced” tab, select the “Serial Port 1 Configuration”. - Page 47 UNO-238 V2 User Manual...
-
Page 48: Serial Port 2 Configuration
Serial Port 2 Configuration The UNO-238 V2 systems support Serial port 2 RS-232/RS-422/RS-485 mode. Power on the UNO-238 V2 system and press “Delete” to enter the BIOS config- uration menu. On the “Advanced” tab, select the “Serial Port 1 Configuration”. - Page 49 UNO-238 V2 User Manual...
-
Page 50: Gpio Configuration
GPIO Configuration The UNO-238 V2 systems support GPIO 0~7. Power on the UNO-238 V2 system and press “Delete” to enter the BIOS config- uration menu. On the “Advanced” tab, select the “GPIO Configuration”. Choose “Input / Output” to GPIO 0~7. - Page 51 UNO-238 V2 User Manual...
-
Page 52: Canbus Configuration
CANBus Configuration The UNO-238 V2 systems support CANBus (Optional). Power on the UNO-238 V2 system and press “Delete” to enter the BIOS config- uration menu. On the “Advanced” tab, select the “iManager Configuration”. Select “ACPI Report Method Configuration”. Select “ACPI Report Method Control”, choose “Custom”. - Page 53 UNO-238 V2 User Manual...
- Page 54 UNO-238 V2 User Manual...
- Page 55 UNO-238 V2 User Manual...
- Page 56 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2023...
