sends to the server. This list details the protocols and encryption methods it can support. The
purpose of the algorithm list is that the client is trying to find a matching set of
protocols/methods supported by the server. The server examines the list and attempts to find a
combination of the protocols/methods sent by the client which it can support. This matching
process is one of the key purposes of the IKE exchange.
Received IKE packet from 192.168.0.10:500 Exchange type :
Identity Protection (main mode) ISAKMP Version : 1.0
Flags :
Cookies : 0x6098238b67d97ea6 -> 0x00000000
Message ID : 0x00000000
Packet length : 324 bytes
# payloads : 8
Payloads:
SA (Security Association)
Payload data length : 152 bytes
DOI : 1 (IPsec DOI)
Proposal 1/1
Protocol 1/1
Protocol ID
SPI Size
Transform 1/4
Transform ID
Encryption algorithm
Key length
Hash algorithm
Authentication method
Group description
Life type
Life duration
Life type
Life duration
Transform 2/4
Transform ID
Encryption algorithm
Key length
Hash algorithm
Authentication method
Group description
Life type
Life duration
Life type
Life duration
Transform 3/4
Transform ID
Encryption algorithm
Hash algorithm
Authentication method
Group description
Life type
Life duration
Life type
Life duration
Transform 4/4
Transform ID
Encryption algorithm
Hash algorithm
Authentication method
Group description
Life type
Life duration
Life type
Life duration
VID (Vendor ID)
Payload data length : 16 bytes
Vendor ID : 8f 9c c9 4e 01 24 8e cd f1 47 59 4c 28 4b 21 3b
Description : SSH Communications Security QuickSec 2.1.0
VID (Vendor ID)
Payload data length : 16 bytes
Vendor ID : 27 ba b5 dc 01 ea 07 60 ea 4e 31 90 ac 27 c0 d0
Description : draft-stenberg-ipsec-nat-traversal-01
VID (Vendor ID)
Payload data length : 16 bytes
Vendor ID : 61 05 c4 22 e7 68 47 e4 3f 96 84 80 12 92 ae cd
: ISAKMP
: 0
: IKE
: Rijndael-cbc (aes)
: 128
: MD5
: Pre-Shared Key
: MODP 1024
: Seconds
: 43200
: Kilobytes
: 50000
: IKE
: Rijndael-cbc (aes)
: 128
: SHA
: Pre-Shared Key
: MODP 1024
: Seconds
: 43200
: Kilobytes
: 50000
: IKE
: 3DES-cbc
: MD5
: Pre-Shared Key
: MODP 1024
: Seconds
: 43200
: Kilobytes
: 50000
: IKE
: 3DES-cbc
: SHA
: Pre-Shared Key
: MODP 1024
: Seconds
: 43200
: Kilobytes
: 50000
