Go to: Objects > Services > Add > TCP/UDP Service

Name: pop3_client_service

Destination: 110

ALG: pop3_client_alg

C. Create an IP Rule for email traffic from the mail server:

Go to: Policies > Firewalling > Main IP Rules > Add > IP Rule

Name: pop3_mail

Action: Allow

Service: pop3_client_service

Source Interface: lan

Source Network: lan_net

Destination Interface: dmz

Destination Network: mail_server_ip

Note that clients initiates the POP3 connection so they are the source for the IP rule.

6.2.8. The PPTP ALG

The PPTP ALG is provided to deal with a specific issue when PPTP tunnels are used with NAT.

Let us suppose we have two clients A and B on a protected inner network behind a NetDefend

Firewall. The firewall is connected to the external Internet and a NAT rule is defined to allow

traffic from the clients to flow to the Internet. Both clients will therefore appear to have from the

same IP address as they make connections to servers across the Internet.

One client A now establishes a PPTP tunnel to an external host C across the Internet. The tunnel

endpoints are the client and the external server. Because of the NAT IP rule, the tunnel

connection will appear to be coming from the external IP address on the firewall.

This first connection will be successful but when the second client B also tries to connect to the

same server C at the same endpoint IP address, the first connection for A will be lost. The reason

is that both clients are trying to establish a PPTP tunnel from the same external IP address to the

same endpoint.

Chapter 6: Security Mechanisms
