Enabling Snmp Version 3 Monitoring - D-Link NetDefendOS User Manual

• Network: mgmt-net
4. For Authentication enter:
• Community: Mg1RQqR
5. Click OK
Should it be necessary to enable SNMP Before Rules (which is enabled by default) then the
setting can be found in System > Device > Remote Management > Advanced Settings.
Example 2.34. Enabling SNMP Version 3 Monitoring
This example is similar to the SNMP versions 1 and 2c example above, but uses SNMP version 3
instead. It enables SNMPv3 access via the lan interface from the network mgmt-net. Both
SNMPv3 authentication and encryption will be enabled and authentication will be done using
the local database called AdminUsers.
Command-Line Interface
gw-world:/> add RemoteManagement RemoteMgmtSNMP my_snmp_v3
Should it be necessary to enable SNMP Before Rules (which is enabled by default) then the
command is:
gw-world:/> set Settings RemoteMgmtSettings SNMPBeforeRules=Yes
Web Interface
1. Go to: System > Device > Remote Management > Add > SNMP Management
2. Now enter:
• Name: my_snmp_v3
• SNMP Version: SNMPv3
• Security Level: authPriv
3. For Access Filter enter:
• Interface: lan
• Network: mgmt-net
4. For Authentication enter:
• Local User Database: AdminUsers
5. Click OK
Chapter 2: Management and Maintenance
Interface=lan
Network=mgmt-net
SNMPversion=SNMPv3
LocalUserDatabase=AdminUsers
Snmp3SecurityLevel=authPriv
114
