3. Click OK and repeat for all 5 public IPv4 addresses
Create a SAT rule for the translation:
1. Go to: Policies > Firewalling > Main IP Rules > Add > IP Rule
2. Specify a suitable name for the rule, for example SAT_HTTP_To_DMZ
3. Now enter:
• Action: SAT
• Service: http-all
• Source Interface:any
• Source Network: all-nets
• Destination Interface: wan
• Destination Network: wwwsrv_pub
• SAT Translate: Destination IP
• New IP Address: wwwsrv_priv
4. Click OK
Finally, create a corresponding Allow rule:
1. Go to: Policies > Firewalling > Main IP Rules > Add > IP Rule
2. Specify a suitable name for the rule, for example Allow_HTTP_To_DMZ
3. Now enter:
• Action: Allow
• Service: http-all
• Source Interface:any
• Source Network: all-nets
• Destination Interface: wan
• Destination Network: wwwsrv_pub
4. Click OK

7.4.4. All-to-One IP Translation

NetDefendOS can be used to translate a range or a network to a single IP address. Suppose that
the requirement is to translate a range of destination IPv4 addresses which includes 194.1.2.16 to
194.1.2.20 plus 194.1.2.30 to the single IPv4 address 102.168.0.50. The port number will remain
unchanged.
