Note: Interface sockets connected via a switch fabric
Some hardware platforms for NetDefendOS use an integrated layer 2 switch for
providing additional physical Ethernet interface sockets. Externally there can be several
separate sockets but these are joined via an internal switch fabric.
Such joined interfaces are seen as a single interface by NetDefendOS and the
NetDefendOS configuration uses a single logical interface name to refer to all of them.
The specifications for different hardware models will indicate where this is the case.
Ethernet Properties
An Ethernet object in a NetDefendOS configuration corresponds to a physical Ethernet interface.
The following are the key properties that can be set for this type of object:
• Interface Name
The names of the Ethernet interfaces are predefined by the system, and are mapped to the
names of the physical interfaces.
The names of the Ethernet interfaces can be changed to better reflect their usage. For
example, if an interface named dmz is connected to a wireless LAN, it might be convenient to
change the interface name to radio. For maintenance and troubleshooting, it is
recommended to tag the corresponding physical interface with the new name.
Note: Interface enumeration
The startup process will enumerate all available Ethernet interfaces. Each interface
will be given a name of the form lanN, wanN and dmz, where N represents the
number of the interface if the NetDefend Firewall has more than one of these
interfaces. In most of the examples in this guide lan is used for LAN traffic and wan is
used for WAN traffic. If the NetDefend Firewall does not have these interface names,
please substitute the references with the actual names of the interfaces.
• IP Address
Each Ethernet interface is required to have an Interface IP Address, which can be either a static
address or an address provided by DHCP. The interface IP address is used as the primary
address for communicating with the system through the specific Ethernet interface.
NetDefendOS IP4 Address objects are usually used to define the IPv4 addresses of Ethernet
interfaces. Those objects are normally auto-generated by the system. For more information,
please see Section 3.1.5, "Auto-Generated Address Objects".
Tip: Specifying multiple IP addresses on an interface
Multiple IP addresses can be specified for an Ethernet interface by using the ARP
Publish feature. (For more information, see Section 3.5, "ARP").
• Network
