38
Display
1 Points 1–16 Base Alarms
1 Points 17–18 Relays
1 Relay/Housekeeping *
2..3 Analog Channels 1..2
Table B.2 Display descriptions and SNMP Trap numbers for the NetGuardian 216
* The Trap number ranges shown correspond to the point range of each display. For example, the SNMP Trap Set
number for alarm 1 (in Display 1) is 8001, Set for alarm 2 is 8002, Set for alarm 3 is 8003, etc.
** The TRAP number descriptions for the Analog channels (1-8) are in the following order: minor under, minor
over, major under, and major over. For example, Analog channel 1, the Set number for minor under is 8065,
minor over is 8066, major under is 8067, and major over is 8068.
Description
POINTS DESCRIPTION
5 SNMP Processing Error
6 SNMP Community Error
7 LAN Tx Packet Drop
Table B.3 Display 1 System Alarms point descriptions
SNMP Trap Numbers *
Set Clear
8001–8016 9001–9016
8017–8018 9017–9018
8025–8032 9025–9032
8065–8128 9065–9128
SNMP TRAP #S
SET CLEAR
8030 9030
8031 9031
8032 9032
