Connections; Antenna "Ant" Connection; Ac Power - PDi -P19LCDC User Manual

Connections

•
Do not connect the power cord until all other connections have been made.
•
Ensure that you observe and correctly connect colored cables when connecting audio and
video cables.

Antenna "ANT" Connection

An "F" style jack is located on the TV's connector panel
.
CAUTION: Some hospital cable
systems provide power voltage
on the coaxial cable. This TV is
NOT designed to be powered
via a coaxial cable. Do not
connect to a powered coaxial
cable. Damage will result to the
TV.

AC POWER

A right-angled AC power cord 1meter in
length is supplied with each TV.
Select a location that is near an AC wall
outlet and that does not expose the TV to
bright room lights or sunlight if possible.
Connect the AC power cord to a powered
outlet.
CABLE ROUTING
Route all cables through the opening
located at the bottom of the cabinet.
22
Hospital Coax Cable
