PDi -P19LCDC Quick Start Manual

P19 hospital grade television
Hide thumbs Also See for PDI-P19LCDC:

Advertisement

Quick
Start
Guide
Communication
Systems, Inc
.
40 Greenwood Lane
Springboro, Ohio
45066
PH: 937-743-6010
FX: 937-743-5664
http://www.pdiarm.com
P19 Hospital Grade television
Better Solutions Are Within Reach®
Model: PDI-P19LCDC
Document Number: PD196I126R1.DOC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PDI-P19LCDC and is the answer not in the manual?

Questions and answers

Summary of Contents for PDi PDI-P19LCDC

  • Page 1: Quick Start

    Quick Start Guide P19 Hospital Grade television Model: PDI-P19LCDC Communication Systems, Inc 40 Greenwood Lane Springboro, Ohio 45066 PH: 937-743-6010 FX: 937-743-5664 http://www.pdiarm.com Better Solutions Are Within Reach® Document Number: PD196I126R1.DOC...
  • Page 2: Safety Instructions

    Only put a DVD or CD into the slot. STACKING Place the unit in a horizontal place, and DO NOT lay anything heavy on it. PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH +1-937-743-6010 FX +1-937-743-5664 Document Number: PD196I127R1.DOC...
  • Page 3: Installation

    Use only with the cart, stand, tripod, bracket or table specified by the manufacturer or sold with the TV. Use caution when moving the cart. WARNING: To reduce the chance of fire or electric shock, only utilize the accessories recommended by the manufacturer. PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH +1-937-743-6010 FX +1-937-743-5664 Document Number: PD196I127R1.DOC...
  • Page 4: Fcc, Copyright, Disclaimer, And Trademarks

    Consult the dealer or an experienced radio/TV technician for help. Copyright PDI Communication Systems, Inc. claims proprietary right to the material disclosed in this user manual. This manual is issued for user information only and may not be used to manufacture anything shown herein. Copyright 2009 by PDI Communication Systems, Inc.
  • Page 5 Jumper Cable, and CATV Coax Cable. 5. The TV’s tilt can be adjusted by loosening both Pilfer Screws, adjusting tilt, and then tightening the screws. Figure 2 PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH +1-937-743-6010 FX +1-937-743-5664 Document Number: PD196I127R1.DOC...
  • Page 6: Across Room Wiring

    ¼” to ¼” Jumper ¼” to 6-Pin Jumper Cable Cable SPEAKER DATA / SWITCH SPEAKER COMMON COMMON DATA / SWITCH ACROSS-ROOM WIRING PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH +1-937-743-6010 FX +1-937-743-5664 Document Number: PD196I127R1.DOC...
  • Page 7: Antenna "Ant" Connection

    Hospital Coax Cable AC Power A right-angled AC power cord is attached to each TV. Connect the AC power cord to a powered outlet. PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH +1-937-743-6010 FX +1-937-743-5664 Document Number: PD196I127R1.DOC...
  • Page 8: Product Accessories

    Press ◄ or ► to select Air, Cable STD, Cable IRC, or Cable HRC. NOTE: Most hospitals use the Cable STD signal style. PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH +1-937-743-6010 FX +1-937-743-5664 Document Number: PD196I127R1.DOC...
  • Page 9: Auto Program

    NOTE: Digital channel auto programming may take longer than 10 minutes to complete. Press the SETUP button to return to normal TV viewing. PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH +1-937-743-6010 FX +1-937-743-5664 Document Number: PD196I127R1.DOC...
  • Page 10: Save Settings To Sd Card

    A progress screen will appear as the settings are restored. Press ◄ twice to return to the Cloning Main Menu. 10. Remove the SD card to return to normal TV operation. PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH +1-937-743-6010 FX +1-937-743-5664 Document Number: PD196I127R1.DOC...
  • Page 11: Installation Instructions

    Press ▼ to highlight SLOT DVD. Press ◄ or ► to change the source status to Enabled/APO. To exit, press SETUP until the programming menus disappear. PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH +1-937-743-6010 FX +1-937-743-5664 Document Number: PD196I127R1.DOC...
  • Page 12: Disc Playback

    OK button to select it. Additional Information Additional information is available in the user manual, Document Number: PD196I149.doc. PDi Communication Systems, Inc. 40 Greenwood Lane Springboro, Ohio 45066 USA PH +1-937-743-6010 FX +1-937-743-5664 Document Number: PD196I127R1.DOC...
