Installation

LOCATION GUIDELINES

The model PDI-P19LCDC Hospital Grade LCD TV is a specialized LCD television. This TV is
intended for entertainment and educational purposes for use in a hospital, a nursing home, a
medical-care center, or a similar health-care facility in which installation is limited to a
non-hazardous area in accordance with the National Electrical Code, ANSI/NFPA 70. The
PDI-P19LCDC is designed for mounting to PDi manufactured mounts. Installation of the TV on any
other mount is not recommended.
The PDI-P19LCDC mounts at the foot of a patient's bed with the supplied bracket. Select a location
that is near an AC wall outlet and that does not expose the TV to bright room lights or sunlight if
possible. The LCD TV also requires connection of both CATV cable signal and across-room wiring
for the pillow speaker.

OSHPD (State of California Only)

The combined weight of the PDI-P19LCDC TV and PDI wall mount totals less than 20 pounds. At
the time of this writing, the involvement of a written, submitted, reviewed, and approved plan by
OSHPD is not required to install the PDI-P19LCDC TV in the state of California.

CABLE SYSTEM GROUNDING

The coax cable system connected to the PDI-P19LCDC TV should be grounded in accordance with
the National Electrical Code, ANSI/NFPA 70. The code provides guidelines for proper grounding
and, in particular, specifies that the cable ground shall be connected to the grounding system of the
building, as close to the point of the cable entry as practical.
WARNING: The TV's VESA mounting holes are designed for M4 metric
screws only. Use of a non-PDi approved mount or SAE hardware could
result in a condition where the TV could unexpectedly fall and cause injury
or death.
17
Document Number: PD196-120 Rev 2
