Indicator, buzzer and button

2.4
There is one button, one buzzer and three indicators on POS88VI printer.
【FEED】is paper feed button. The function of this button is on/off can be set
by print command. When the function of this button is on, press【FEED】
button to feed paper; release【FEED】button to stop feeding button.
The buzzer can indicate the error and cutter status. Through parameters
setting, the buzzer can be set into error alarm, paper-cut indicating or both
above. The types of error status are same as ERROR indicator.
The green POWER light is the power indicator. POWER indicator lighting
means the printer is power on.
PDF created with pdfFactory trial version
Pin No. Signal
1
+24VDC
2
Ground
3
NC
The pin assignment is as above:
